PREMIUM HARD TO FIND PC ITEMS:
RARE NEW VINTAGE ASUS P4B266-VMX SOCKET 478 P4 MICRO ATX MOTHERBOARD VGA LAN SOUND MBMX14. MANUAL,Drivers and Cables NOT included. Fully Tested. OEM Surplus.
Search "P4B-MX Specs" and download full 112-pagemanual from motherboards.org
** USA Seller ** THE ONLY USA LISTING on ! COMPARE TO $169 TO $272 on the WEB! OEM DIRECT INVENTORY!
FLAT USPS PRIORITY Shipping
US-RM1-MBMX14-0000
SPECS:
MOTHERBOARD MODEL:Asus P4B266-VMX
CPU SUPPORT:
Socket 478 for FC-PGA2 Pentium 4 (Willamette/Northwood) 1.4GHz to 2.4GHz+
CHIPSET:
North Bridge: Intel 82845D Memory Hub (Brookdale)
South Bridge: Intel 82801BA I/O Hub 2 (ICH2)
FSB:
Adjustable FSB up to 800 MHz.
SYSTEM MEMORY:
2 slots for PC2100/PC1600 DDR SDRAM
Up to 2 GB
EXPANSIONS SLOTS:
3 x PCI
1 x AGP 4X
ON BOARD IDE:
ATA-100/66/33 support
ON BOARD Audio:
AC ' 97 Audio Codec Controller (optional)
ON BOARD Video:
On-Board AGP video
ON BOARD LAN:
Realtek RTL8100 100/10Mbps Ethernet LAN Controller
Rear Panel ports:
PS/2 Mouse and Keyboard Ports
One 9-pin 16550 UART Serial port
One 25-pin ECP/EPP Parallel port
One VGA port
Four USB 1.1 ports
One RJ45 LAN port
Audio in/out/mic ports
SPECIAL FEATURES:
Hardware Monitoring
ASUS ASIC MOZart_2
LAN Onboard (Option)
Intel 100/10Mbps Ethernet LAN Controller
BIOS:
Award BIOS
Plug and Play
DIMENSIONS:
Micro ATX Form Factor. 9.6" x 9.6"
