These DB9 Male/Female Solderless Connectors are used to terminate the connection type of a cable. They can easily be connected to a custom length cable as well as create a custom pinout, creating a permanent and durable connection for all applications. These connectors are made with high-quality materials to ensure durability and a long life.
Technical Specifications:
Name: DB9 solderless module
Plug type: One Male, one Female
Accessories: housing, screw, card line buckle
Connector material: pure copper plated joint
Material: Copper
Housing material: environmentally friendly PP engineering materials
Shell type: folding snap-on
Pin Pitch: 3.81mm/0.15in
Cable Specification: 28-16 AWG/0.15-1.5mm2
Torque: 0.2Nm (1.7Lb-In.)
Opening size (cable port): 10.5mm/0.41″
Application: tax control machine, digital camera, PLC, PDA, MODEM, set-top box, barcode machine, industrial instrumentation, etc.
Size: 53 mm×34 mm×21.5 mm/ 2.09″×1.34″×0.85″
Package includes:
5 x DB9 Male Solderless Connectors
5 x DB9 Female Solderless Connectors
10x Cable pressing plate
20x Screws
20x Long bolts
10x 5mm tail pipe
10x 6mm tail pipe
10x 7.5mm tail pipe
10x 8.5mm tail pipeHIGH QUALITY&DURABLE: Pure copper plated joints, fine solder joints, resistance to plug, and good to ensure high-quality, durability and a long life. The outer casing is made of environmentally friendly PP engineering material, which is soft and durable.
EASY TO USE: No welding required, 128 type environmental protection copper terminal design, no need for soldering iron and cumbersome tools, easy wiring. The housing is designed with a folding buckle for easy assembly and disassembly without tools.
HIGH COMPATIBILITY: It can connect all kinds of serial devices. Such as computer and tax control machine, digital camera, PLC, PDA, MODEM, set-top box, barcode machine, industrial instrumentation and other equipment for communication.
HOMMIZATION: Each set of products is equipped with a set of cable pressing plate to prevent easy remoHOMMIZATION: Each set of products is equipped with a set of cable pressing plate to prevent easy removal of the connected wires; Shell with non-slip design.val of the connected wires; Shell with non-slip design.
INTUITIVE: All signal ports are clearly named and labeled on both sides of the board for quick wiring.
