2DHigh Speed Toolpaths For -MastercamX9, X8, X7, X6, X5, X4
HighSpeed Toolpaths Covered.
* Introduction To 2D HST
* Parameter Overview
* 2D HST Area Mill
* 2D HST Peel Mill
* 2D HST Blend Mill
* 2D HST Dynamic Area
* 2D HST Dynamic Rest
* 2D HST Dynamic Core
* 2D HST Dynamic Contour
* 2D HST Open Pockets
* 2D HST Pockets w/ Islands
* 2D HST Air Regions (X9, X8)
* 2D HST Entry Motion Options (X9, X8)
Mastercam’s2D HST toolpaths are the foundation oftoday’sinnovative machining concepts. If you're aJob Shop looking to improve efficiency, reduce cutting time and getbetter utilization of your tooling, 2D HST is theanswer. First Time Users and Long Time Users Will Both FindThis CD Informative.
No Internet Connection Required. No Monthly Subscription. The CD NeverExpires. Watch These Lessons Any Time That’s Convenient ForYou.
Covers everything you need to get started making toolpaths. Detailedinformation about theMastercam2D High Speed Toolpaths, hotkeys, importing CAD files, Custom Toolbars,Custom Menus, Custom Configurations and Verification options. Includessample parts in Parasolid andMastercamformats. MastercamControl.
* Mouse/Interface Control
* Hotkey Short Cuts
* Optimizing Cycle Time
* Relative Coordinate Picks
* WCS/Zero Shift (G54-G55)
* Chaining/Selection Options
* Working With Planes
* Changing Entity Colors
* Changing Entity Levels
* Geometry Selection
Theselessons will apply the 2D HST Toolpaths to your everyday machining.Includes many "real world" part examples, demonstrating how to machineon multiple planes (tops and bottoms) of a single part. CreatingConstruction Planes, Work Coordinate Systems, Fixture Offsets, ShiftingZero and Multiple Toolpath Group.
InterfaceCustomization
* Custom ToolBars
* Custom Right Click Menus
* Custom Configurations
* Configuration Backups in the Operations Manager.
OtherFunctions Covered.
* Multiple Machine Groups
* Multiple Toolpath Groups
* Multiple Planes
* Shifting Zeros
* Work Offsets
* Contour Toolpaths
* Incremental / Absolute
* Rapid Clearance Control
* Lead In / Lead Out
* High Speed Cutting Logic
* Data From The Model
* Linking Parameters
Contentsof the MastercamX9, X8 CD
4 Hours of Video with Audio Narration.
35 HD Lessons.
6 Different parts
9 Different Projects.
Contents of the MastercamX7, X6 CD
5 Hours of Video with Audio Narration.
55 HD Lessons.
5 Different parts
9 Different Projects.
Contents of the MastercamX5, X4 CD
4.5 Hours of Video with Audio Narration.
55 HD Lessons.
8 Different parts
FeatureBased Machining.(X7, X6, X5 only)
* Learn To Use FBMachining
* Set Toolpath Options
* Set Tool Size Ranges.
* Limit Operations By Plane
* Include/Exclude Roughing
* Control Rest Roughing
* Reduce Operation Creation
* Edit Operations
* FBM Drilling
* Create Tapped Holes
* Mapping Tapped Holes Personal,Professional Training Anytime You Want It.
This CD Rom runs in 1280 x 800 resolution on any PC with any WebBrowser. Microsoft Windows XP, thru Win 11 Compatible. HighResolution video, with audio narration. A CD\DVD drive, Sound card& Speakers are required.
No Internet Connection Required. No Monthly Subscription. The CD NeverExpires. Watch These Lessons Any Time That’s Convenient ForYou.
