Note：The only Official store on !! Lowest price!
100% New and szhuashi Wireless Technology Co., Ltd. shipped directly from the original factory
Original factory direct delivery! Lots of stock! 100% genuine guarantee! Support customization!Packing List (bulk pack):
1 x Booster
1 x Power adapter
1 x SMA cable
1 x Antenna
Description
This 2.4&5.8 GHz WLAN signal booster is designed for IEEE 802.11 n/ac Wireless LAN applications. It adopts the direct sequence spread spectrum(DSSS) and orthogonal frequency division multiplexing (OFDM) technology of WLAN communication. The product is compatible with time division duplexing (TDD) method of WLAN and using rapid microwave detection technology to provide high linearity amplification. The signal booster can work with most WLAN/Wi-Fi devices and increase the WLAN signal strength, therefore a larger WLAN coverage and more stable transmission rate.
Applications
2.4&5.8GHz wireless LAN access points and clients
2.4&5.8GHz WLAN base station
2.4&5.8GHz WLAN bridge
Drone,image transmission,aeromodelling, etc.
Specifications
Frequency Range: 2400-2500MHz,5720-5850 MHz
Operating Voltage: 12V
Receiving Gain: 12dB±1
Transmission Gain: 13dB±1
Input Trigger Power: Min: 10dBm Max: 22dBm
Maximum Output Power (P1dB): 34±1dBm (2.5W)
Operating Current：350mA@Pout 27dBm 12V
Noise Figure: ≤3.5dB
TX/RX Switch Time Delay：≤1us
LED Indicator: Transmitter: Green; Receiver: Red
Operating Ambient Temperature: -20℃～+60℃
Operating Humidity: ＜95%RH
Dimension: 118mm×59mm×17mm
Net Weight: 135g
Power Supply Port:DC
RF interface： SMA external thread internal hole
