FEATURES

Guaranteed 850W of Continuous Power from Antec

100% Modular－Improves airflow and reduces clutter

80 PLUS® GOLD certified－Up to 92% efficient, to reduce yourelectricity bill

PhaseWave™ Design－A server-class full-bridge LLC designwith a synchronous rectification based on a DC-DC topology

Antec Quality 10-year warranty and lifetime global 24/7support

120mm FDB Silence－Whisper-quiet high-qualityfluid-dynamic bearing fan with long lifetime

Zero RPM Manager－An advanced low voltage fan controlwith fan-off mode at low loads for absolute silence

99%+12V - Output for maximum CPU & GPU support

100% Japanese capacitors achieve unprecedented tight voltageregulation & low ripple & noise to maximize your system’s performance

28(18+10) pin MBU socket - For possible future MBUconnectors

ATX12V 2.4－Engineered according to the newest PSU guideline andcompatible with the latest CPU generation

Compact size 140mm depth power supply is the best choice forcompact ATX chassis

SPECIFICATIONS

Model HCG850 Gold

Type ATX 12V 2.4

Modular FullyModular

Dimension (W x L x H) 140(L)*150(W)*86(H)mm

Warranty 10years

Input Voltage 100-240VAC ±10%

Input Current 12A-6A

Input Frequency Range 50Hz-60Hz

PFC Active PFC(>0.9 typical)

Power Good Signal 100-500ms

Efficiency 92%Typically

Protection OCP/OVP/UVP/SCP/OPP/OTP/SIP/NLO

Output Capacity 850W

Operation Temperature 0~40°C

Regulatory cTUVus/TUV/CB[IEC62368 Compliant] /RCM/CE/EAC/CCC/BSMI/FCC/KR

Fan 120mm FDBFan

Certifications 80Plus Gold

Connector 1 xMB 24(20+4) Pin

2 x 8(4+4) Pin EPS 12V

6 x 8(6+2) Pin PCI-E

10 x SATA

5 x Molex

1 x FDD

Net Weight 2.46Kg

Gross Weight 3.77Kg
