height="28px" valign="middle" face="arial" style="text-decoration:none" to our storeDear valued buyer, thank you for viewing our items.
We will provide you the best service and high quality products.
Each motherboard will be tested before shipping, we ensure it 100% working, and with safty package.
You must be happy to do business with us.

Warm Tips

1. Please do usegenuinebrand RAM, this motherboard can't work with fake RAM.2. If the motherboard can't run correctly, please first check your CPU whether can be compatible with our motherboard.3. Most of "can't boot" problem was caused by RAM, please don't use "single side" RAM.Sepcifiction

CPU

AMD Socket AM3 ;Phenom™II /Athlon™II /Sempron™ 100 Series Processors
AMD Cool 'n' Quiet™ Technology
Supports 45nm CPU

Chipset

AMD 785G/SB710

System Bus

Up to 5200 MT/s HyperTransport™ 3.0

Memory

4 x DIMM, Max. 16 GB, DDR3 1800(O.C.)*/1600(O.C.)/1333/1066/800 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*AMD AM3 100 and 200 series CPU support up to DDR3 1066MHz
**Due to OS limitation, when installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Install a 64-bit WindowsWindows® OS when you want to install 4GB or more memory on the motherboard.

Expansion Slots

2 x PCIe 2.0 x16 (blue at x16 mode,gray at x4 mode)
1 x PCIe x1
3 x PCI

Multi-GPU Support

ATI® CrossFireX™ Technology

VGA

Integrated ATI Radeon™ HD 4200 GPU
SidePort Memory - onboard 128MB DDR3 1333 memory
- Supports HDMI™ Technology with max. resolution up to 1920 x 1200 (1080P)
- Supports Dual-link DVI with max. resolution up to 2560x1600 at60Hz
- Supports D-Sub with max. resolution up to 2048x1536 at85Hz
- Hybrid CrossFireX™ Support
- Dual independent displays support with HDMI / DVI and D-Sub
- Supports Microsoft® DirectX 10.1, OpenGL 2.0, Shader Model 4.1
- Hardware Decode Acceleration for H.264,VC-1, and MPEG-2
- Maximum shared memory of 512MB

Storage

SB710 Chipset
1 xUltraDMA 133/100/66 for up to 2 PATA devices
5 xSATA 3 Gb/s ports Support RAID 0,1,10,JBOD
1 x eSATA 3Gb/s port

LAN

RTL8112L Gigabit LAN controller featuring AI NET 2

Audio

VT1708S 8-Channel High Definition Audio CODEC
- Supports Jack-Detection, Multi-Streaming, and Front Panel Jack-Retasking
- Optical S/PDIF Out ports at back I/O

IEEE 1394

VT6308P controller supports 2 x 1394a port(s) (1 at mid-board; 1 at back panel)

USB

12 USB 2.0/1.1 ports (6 ports at mid-board, 6 ports at back panel)

ASUS Unique Features

ASUS Power Solutions:
- 8+2 Phase Power Design
ASUS Green Design:
- EPU
Express Gate
ASUS Quiet Thermal Solution:
- ASUS Fanless Design: Stylish heat sink solution
- ASUS Q-Fan
ASUS EZ DIY:
- ASUS CrashFree BIOS 3
- ASUS MyLogo 2
- ASUS EZ Flash 2

Overclocking Features

Intelligent overclocking tools
- Turbo V
- GPU NOS (*GPU NOS does not take effect under Hybrid CrossFireX mode.)
- Turbo Key
SFS (Stepless Frequency Selection)
- FSB tuning from 200MHz up to 550MHz at 1MHz increment
- PCI Express frequency tuning from 100MHz up to 150MHz at 1MHz increment
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)

Special Features

100% All High-quality Conductive Polymer Capacitors
AMD OverDrive Support*
*Advanced cooling system is required when advanced overclock functions of AMD OverDrive are enabled.

Back Panel I/O Ports

1 x PS/2 Keyboard/Mouse Combo port
1 x DVI
1 x D-Sub
1 x HDMI
1 x External SATA
1 x S/PDIF Out (Optical)
1 x IEEE 1394a
1 x LAN(RJ45) port
6 x USB 2.0/1.1
8 -Channel Audio I/O

Internal I/O Connectors

3 x USB connectors (6 ports)
1 x COM connector
1 x IDE connector
5 x SATA connectors
1 x CPU Fan connector
1 x Chassis Fan connectors
1 x Power Fan connector
Front panel audio connector
1 x IEEE 1394a connector
1 x S/PDIF Out Header
1x LPT connector
24-pin ATX Power connector
4-pin ATX 12V Power connector
System Panel

BIOS

8 Mb Flash ROM AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.3, ACPI 2.0a, ASUS EZ Flash 2, ASUS CrashFree BIOS 3

Manageability

WOL by PME,WOR by PME,WOR by Ring,PXE

Form Factor

ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

AccessoriesPlease note only the following accessories come with the mobo:

• 1 x motherboard
• 2 x SATA cables
• 1 x I/O back pannel


Shipping & Handling

Item will be shipped within 1-2 working days (business days) after full payment is received

To USA,AUS,CA,UK,EU,Europe,will be shipped by via air mail service,need around 10-25 days.and other countries need around 15-35 days.In case you haven't recieved the packet, please check with your local post office first, because the packet will arrive there. Duo to different country, some local post office can't offer more detailed tracking status in time, it perhaps only show the shipment infor just left Hong Kong.

If you want to get it fast(4-7 days),Please choose expedited shipping,It must add 18-30us shipping fee (according to your country).

Please note, it maybe bring the customs tax, please understand these fees were not included in your payment, these fees will be collected by the delivery company, when sign for the packet. Please inquire your country customs office about the tax before perchasing.

Custom tax

• Please note we're unable to take any responsibility for any custom delay or tax. The fees of import duty/tax are not included in the item price or shipping fee, these are the buyer's responsibility.

• Please check with your local custom office to determine what these additional costs would be before payment. And these fees are normally collected by the delivery company, when you pick up item.

Return PolicyDear friend, the warranty is 90 days, in case the mobo exist problem, and you want to refund or replace, plase read this before purchased.

• Refund: Refund can be accepted in 90 days after you signed the package. Please send back the item in original package with all the accessories in it. When you shipped back, please give us tracking number. Generally speaking,refund or replacement will be made upon receipt of the returned item.
• Replace: Replace can be accepted in 90 days after you signed the package. Please send back the item in original package, needn't return any accessories. When you shipped back, please give us the tracking number. We'll resend another mobo to you, as soon as we got the returned package.
• Both shipping cost: The cost of item shipping back is buyer's responsibility, the resend shipping cost is seller's.
• Wrong order: Dear friend, I think you have thought over before bought the item. But in case you got a wrong mobo, please first check out your order form, whether we sent a wrong mobo or your ordered a wrong mobo. Please note if you order wrong, we don't accept the refund or replace.


Customer Service

• we sincerely do business with you. If you satisfy with our service and products, please leave us positive response. Your recognition is our power to move forward, especially to a beginner like us. Your great comments will lead us to get more potential customers, and make us more confident to develop business and serve you better.
• But if you don't satisfy with the item, or you have any concern about our transaction, please do first contact us, we will response you in 24 hours, and do our best to help you solve any problems.
• All communications are handled through Email. We strive to answer all emails as quickly as possible style="text-decoration:none"
