Product parameters:

Fan speed (RPM): 1800RPM±10%

Radiator dimension: L123.5mm*W120mm*H67

Fan size: L120mm*W120mm*H15mm

Radiator height: 67mm

Cooling method: air cooling

Power interface: 4pin

CPU socket support: Intel: 115X/1200/20XX/1700;AMD: AM4

6×6mmAGHP III anti-gravity heat pipe,

Noise ≤26.1DBA,

Voltage 12V,

Current 0.18A (MAX),

S-FDB bearing,

Air volume: 59CFM (MAX),

Wind pressure: 1.36mm H2O (MAX),

Material: copper base+aluminum sheet+BLACK PBT+PC fan

Package Contents:

Radiator body × 1

Tl-C12015B-Sfan × 1

Tf7 thermal conductive silicone grease × 1

AMD/INTEL bracket × 2

Blue circle×4

Screw cap × 4(INTEL specific)

Fan wire buckle × 2

card × 1

Blue/Red/Black gel columnx4

Multi platform backplane×1

LGA20XX stud X4

manual × 1

【Brand Overview】is a Taiwan brand with more than 20 years of development. It has a certain popularity in the domestic and foreign markets and has a pivotal influence in the player market. We have been focusing on the research and development of computer accessories. R & D product lines include: CPU air-cooled radiator, case fan, thermal silicone pad, thermal silicone grease, CPU fan controller, anti falling off mounting bracket, support mounting bracket and other commodities.
【Product specification】AXP120-X67 BLACK ARGB 1700; CPU Cooler dimensions: 123.5(L)x120(W)x67(H)mm (4.86x4.72x2.64 inch); low-profile CPU cooler (67mm total height)；Heat sink material: Aluminum fin on copper bottom, CPU cooler is equipped with metal fasteners of Intel & AMD platform to achieve better installation.
【PWM Fan】Model:TL-C12015B-S; Standard size PWM fan:120x120x15mm (4.7x4.7x0.59 inches); fan speed (RPM):1800rpm±10%; power port: 4pin; Voltage:12V; Air flow:59CFM(MAX); Noise Level≤26.1dB(A); Argb port: 5V 3pin ARGB.
【AGHP technique】6×6mm heat pipes apply AGHP technique, Solve the Inverse gravity effect caused by vertical / horizontal orientation,6 pure copper sintered heat pipes & PWM fan & Pure copper base&Full electroplating reflow welding process, When CPU cooler works, match with ultra-silent airflow fans, aim to extreme CPU cooling for Intel: AMD:AM4 AM5; Trusted CPU cooler quality.
