Baicells EG7010A-M11Atom OD06 3.5GHz 14dBi CAT 6 Outdoor CPE Band 42/43/48

Baicells Atom OD06 3.5GHz 14dBi CAT 6 Outdoor CPE Band 42/43/48 provides superior wireless access performance and comprehensive routing capabilities to bring wireless broadband data and voice services to end-users.

It is designed exclusively for the fixed wireless market, featuring a spring-locked gasket door for protecting the SIM slot and eliminating the need for weatherproofing the power and Ethernet connections. Wireless and wired devices, including mobile phones, laptops, tablets and other smart devices, can access the UE simultaneously.

Features:

• Supports LTE TDD bands 40, 41, 42, 43, 48, and customized
• 2.5 GHz or 3.6 GHz models
• Complies with 3GPP Release 10 CAT 6/7 standards
• 1000 Mbps Ethernet interface
• GUI-based local and remote Web management
• TR069 network management protocol support
• Cell lock, SIM lock, and pin lock
• User-friendly LED status indicators
• Built-in LTE bipolar, directional, high-gain antenna
• Power supply with PoE
• Pole or wall mount
• Supports Wi-Fi EG7010A-M11BASIC SPECIFICATIONSLTE Standard3GPP Release 10, CAT 6/7Ethernet LAN PortOne RJ-45 port 10/100/1000 autosensing, auto-MDX, PoELED IndicatorsMIU/LTE/SIM/LAN/PWR/LTE SIGNALUSIM1.8V/3V 2FFRestore ButtonTactile button. Press button for at least 10 seconds to restore UE to factory settingsPower SupplyInput: Universal range 100V to 240V AC Output: PoE (24VDC, 0.5A)Dimensions (HxWxD)9.8 x 9.8 x 3.2 Inches
  248 x 248 x 80 millimetersWeight4 lbs (1800 g)RF SPECIFICATIONSLTE ModeTDDChannel Bandwidth5 / 10 / 15 / 20 MHzMAX Output Power23 ± 2dBm / TX AntCarrier Aggregation2CC CAFrequencyBands* Bands 40, 41, 42, 43, 48, and customizedAntenna Gain14 dBi @ 3.x GHz, 4 ports
  11 dBi @ 2.x GHz, 4 portsCarrier Aggregation*2CC CAPeak RateDL 220 Mbps, UL 15 Mbps (2:7)ModulationDL: QPSK, 16QAM, 64QAM
  UL: QPSK, 16QAM, 64QAMReceive Sensitivity-94 dBm @ QPSK, 20 MHz, 25°CAntenna TypeInternal directional, 2T4R (uplink enhanced)Polarization±45°Antenna Beamwidth (3 dB)60 ±5° @ 2.x GHz, 4 ports
  25 ±5° @ 3.x GHz, 4 portsVertical Beamwidth (3 dB)35 ±5° @ 2.x GHz, 4 ports
  25 ±5° @ 3.x GHz, 4 portsSOFTWARE SPECIFICATIONSNetwork ModeNAT / Bridge / TunnelIP ProtocolIPv4 / IPv6SIMPIN management SIM lockNetwork Connection ManagementAuto / ManualLTE Scan ModeFull band scan, frequency lockWLANWi-Fi for UE alignmentVPNL2TP L2/L3 GRE L2/L3NATPort forwarding Port trigger DMZ ALGStatisticsLTE status; connection/system up time; device status; DHCP client list; Wi-Fi station list; firewall statusFirewallIP/MAC/URL filter; access control; block port scanner/SYN flood; SPI filterNetwork ManagementTR069, TR104, SNMPDiagnosticsTCP dump, ping, tracerouteMaintenanceDate and time setting; reboot; restore factory settings; restore or back up configuration file; firmware upgrade locally or OTASystem LogsOperating; run-time; filter/ select / display / exportWI-FI SPECIFICATIONSStandardIEEE 802.11b/g/nChannel Bandwidth20/40 MHzFrequency2.4 GHzTXRX1T1RPeak Rate802.11b: 11 Mbps
  802.11g: 54 Mbps
  802.11n: 300 MbpsModulationDSSS/CCK, OFDMReceive Sensitivity• -64 dBm @ 65 Mbps, typical for 802.11n • -65 dBm @ 54 Mbps, typical for 802.11g • -76 dBm @ 11 Mbps, typical for 802.11bMax Output Power10 ±3dBmAntenna TypeInternal omni, 1T1RAntenna Gain0 dBiENVIRONMENTOperating Temperature-40°F to 131°F / -40°C to 55°CStorage Temperature-40°F to 158°F / -40°C to 70°COperating Humidity5% to 95%Ingress Protection RatingIP67
