Banana Pi BPI-M2 Zero

Compact Quad-Core SBC with WiFi & Bluetooth 📶

Overview

The Banana Pi BPI-M2 Zero is an ultra-compact single board computer measuring just 65mm x 30mm. Its external interfaces match the layout used by other popular Zero-form-factor boards, so it fits almost all cases and accessories designed for that footprint. Powered by the Allwinner H3 Quad-Core Cortex-A7 processor with 512MB DDR3 RAM, it's ideal for lightweight Linux and Android projects, home automation, retro emulation, and space-limited builds.

Key FeaturesQuad-Core Processing

Allwinner H3/H2+ Cortex-A7 CPU with Mali400MP2 GPU supporting OpenGL ES 2.0 and 1080p video decoding.

WiFi & Bluetooth Onboard

Integrated AP6212 module gives wireless networking and BT connectivity without extra hardware.

40-Pin GPIO Header

Compatible pinout with common 40-pin Zero-form-factor boards, including UART, SPI, and I2C support.

Compact Footprint

At only 65mm x 30mm and 15g, it fits standard Zero-sized cases and accessories.

Choosing Your Option

This listing includes two package options with the same 512MB DDR3 board:

Package 1: Standard board package.
Package 2: Alternate accessory bundle. Please review the seller's package photos for exact included items, as both share the same core board.

SpecificationsCPUAllwinner H3/H2+ Quad-Core Cortex-A7GPUMali400MP2 @600MHz, OpenGL ES 2.0Memory512MB DDR3 (shared with GPU)StorageTF Card (Max 64GB), no onboard storageWirelessWiFi + Bluetooth (AP6212)Video OutputMini HDMI 1.4, 1080p@30fpsVideo InputCSI camera connectorUSB1x USB 2.0 OTGGPIO40-Pin Header, UART/SPI/I2CPowerMicro USB, 5V/2ASupported OSAndroid, LinuxDimensions65mm x 30mmWeight15gProduct ImagesFAQDoes it support wireless connectivity?

Yes, WiFi and Bluetooth are built-in via the onboard AP6212 module.

What operating systems are supported?

Both Android and Linux are supported.

Does it come with storage included?

No onboard storage; use a TF card up to 64GB.

What powers the board?

A Micro USB power supply rated 5V/2A is required (not always included, check package option).
