(Cisco Controller) >show sysinfo
Manufacturer's Name.............................. Cisco Systems Inc.
Product Cisco Controller
Product 8.5.182.0
Bootloader Version............................... 1.0.20
Field Recovery Image Version..................... 7.6.101.1
Firmware PIC 15.0
OUI File Last Update Time........................ Sun Sep 07 10:44:07 IST 2014
Build DATA + WPS
System test
System style="color: rgb(34, 34, 34); font-family: Arial, Helvetica, sans-serif; font-size: small;">System style="color: rgb(34, 34, 34); font-family: Arial, Helvetica, sans-serif; font-size: small;">System 1.3.6.1.4.1.9.1.1279
IP 192.168.2.10
IPv6 ::
Last Software reset
System Up Time................................... 0 days 0 hrs 2 mins 14 secs
--More-- or (q)uit
System Timezone Location.........................
System Stats Realtime Interval................... 5
System Stats Normal Interval..................... 180
Configured Country............................... US - United States
Operating Environment............................ Commercial (0 to 40 C)
Internal Temp Alarm Limits....................... 0 to 65 C
Internal +26 C
External +29 C
Fan 3344 rpm
State of 802.11b Network......................... Enabled
State of 802.11a Network......................... Enabled
Number of WLANs.................................. 1
Number of Active Clients......................... 0
OUI Classification Failure Count................. 0
Memory Current Usage............................. 38
Memory Average Usage............................. 41
CPU Current Usage................................ 0
CPU Average Usage................................ 2
--More-- or (q)uit
Flash Compact Flash Card
Flash 1073741824
Burned-in MAC Address............................ D0:C2:82:E0:1D:40
Maximum number of APs supported.................. 75
System style="color: rgb(34, 34, 34); font-family: Arial, Helvetica, sans-serif; font-size: small;">WLC MIC Certificate Types........................ SHA1
(Cisco Controller) >show inventory
Burned-in MAC Address............................ D0:C2:82:E0:1D:40
Maximum number of APs supported.................. 75
NAME: "Chassis" , DESCR: "Cisco 2500 Series Wireless LAN Controller"
PID: AIR-CT2504-K9, VID: V01, SN: PSJ153501JX
(Cisco Controller) >show license all
License Store: Primary License Storage
StoreIndex: 0 Feature: base Version: 1.0
License Type: Permanent
License State: Active, Not in Use
License Count: Non-Counted
License Priority: Medium
License Store: Primary License Storage
StoreIndex: 0 Feature: base-ap-count Version: 1.0
License Type: Permanent
License State: Active, In Use
License Count: 15 / 15 (Active/In-use)
License Priority: Medium
License Store: Evaluation License Storage
StoreIndex: 1 Feature: base-ap-count Version: 1.0
License Type: Evaluation
License State: Inactive
Evaluation total period: 12 weeks 6 days
Evaluation period left: 12 weeks 6 days
License Count: 75 / 0 (Active/In-use)
License Priority: None
--More-- or (q)uit
(Cisco Controller) >show ap bundle all
Primary Version : 8.5.182.0
AP Supplement Bundle : Installed
Primary AP Image Size Supported AP's
---------------- ---- ------------
ap1g1 13192 AP700
ap1g2 13660 AP1600
ap1g3 15380 AP1530
ap1g4 25872 AP1850/1810
ap1g5 22228 AP1815,1540
ap3g1 10168 AP3500
ap3g2 15380 AP2600,3600
ap3g3 39516 AP2800,3800,1560
ap801 8468 AP802
ap802 9968 AP802
c1550 10948 AP1550(128MB)
c1570 13052 AP1570
c3700 14372 AP1700,2700,3700
--More-- or (q)uit
Secondary Version : 8.3.102.0
AP Supplement Bundle : Installed
Secondary AP Image Size Supported AP's
------------------ ---- ------------
ap1g1 12820 AP700
ap1g2 12872 AP1600
ap1g3 14872 AP1530
ap1g4 21068 AP1850/1810
ap3g1 9768 AP3500
ap3g2 14712 AP2600,3600
ap3g3 25252 AP2800,3800,1560
ap801 8104 AP802
ap802 9588 AP802
c1140 8668 AP802
c1520 7384 AP802
c1550 10656 AP1550(128MB)
c1570 12672 AP1570
c602i 3864 AP802
