1U

IOS-XE 16.09

N/A

ipbasek9

2x PWR-4430-AC (Takes C13 Plug)

Minor signs of prior use, including scratches
scuffs and possible adhesive residue remaining.

Power Cord(s)

Router#show env all
Sensor List: Environmental Monitoring
Sensor Location State Reading
Temp: Temp 1 P0 Normal 34 Celsius
Temp: Temp 2 P0 Normal 37 Celsius
Temp: Temp 3 P0 Normal 39 Celsius
V: PEM Out P0 Normal 11900 mV
I: PEM In P0 Normal 1 A
I: PEM Out P0 Normal 3 A
P: In pwr P0 Normal 37 Watts
P: Out pwr P0 Normal 28 Watts
RPM: fan0 P0 Normal 5920 RPM
Temp: Temp 1 P1 Normal 37 Celsius
Temp: Temp 2 P1 Normal 38 Celsius
Temp: Temp 3 P1 Normal 40 Celsius
V: PEM Out P1 Normal 12000 mV
I: PEM In P1 Normal 1 A
I: PEM Out P1 Normal 3 A
P: In pwr P1 Normal 33 Watts
P: Out pwr P1 Normal 24 Watts
RPM: fan0 P1 Normal 5952 RPM
RPM: fan0 P2 Normal 9324 RPM
RPM: fan1 P2 Normal 9446 RPM
RPM: fan2 P2 Normal 9358 RPM
P: pwr P2 Normal 4 Watts
Temp: Inlet 1 R0 Normal 26 Celsius
Temp: Inlet 2 R0 Normal 33 Celsius
Temp: Outlet 1 R0 Normal 32 Celsius
Temp: Outlet 2 R0 Normal 34 Celsius
Temp: core-A R0 Normal 47 Celsius
Temp: core-B R0 Normal 41 Celsius
Temp: core-C R0 Normal 41 Celsius
V: 12v R0 Normal 11991 mV
V: 5v R0 Normal 5139 mV
V: 3.3v R0 Normal 3344 mV
V: 3.0v R0 Normal 3015 mV
V: 2.5v R0 Normal 2496 mV
V: 1.05v R0 Normal 1057 mV
V: 1.8v R0 Normal 1803 mV
V: 1.2v R0 Normal 1210 mV
V: Vcore-C R0 Normal 1152 mV
V: 1.1v R0 Normal 1107 mV
V: 1.0v R0 Normal 1015 mV
V: 1.8v-A R0 Normal 1795 mV
V: 1.5v-A R0 Normal 1511 mV
V: 1.5v-C1 R0 Normal 1532 mV
V: 1.5v-B R0 Normal 1526 mV
V: Vcore-A R0 Normal 996 mV
V: 1.5v-C2 R0 Normal 1497 mV
V: Vcore-B1 R0 Normal 783 mV
V: Vcore-B2 R0 Normal 904 mV
V: 0.75v-B R0 Normal 759 mV
V: 0.75v-C R0 Normal 764 mV
I: 12v R0 Normal 4 A
P: pwr R0 Normal 46 Watts
Router#show Please use "show license UDI" to get serial number for "Chassis", DESCR: "Cisco ISR4431 Chassis"
PID: ISR4431/K9 , VID: V05 , SN: FJC2309A0XBNAME: "Power Supply Module 0", DESCR: "250W AC Power Supply for Cisco ISR4430"
PID: PWR-4430-AC , VID: V02 , SN: LIT224637UPNAME: "Power Supply Module 1", DESCR: "250W AC Power Supply for Cisco ISR4430"
PID: PWR-4430-AC , VID: V02 , SN: LIT22523E5GNAME: "Fan Tray", DESCR: "Cisco ISR4430 Fan Assembly"
PID: ACS-4430-FANASSY , VID: , SN:NAME: "module 0", DESCR: "Cisco ISR4431 Built-In NIM controller"
PID: ISR4431/K9 , VID: , SN:NAME: "NIM subslot 0/0", DESCR: "Front Panel 4 ports Gigabitethernet Module"
PID: ISR4431-X-4x1GE , VID: V01 , SN:NAME: "module R0", DESCR: "Cisco ISR4431 Route Processor"
PID: ISR4431/K9 , VID: V05 , SN: FOC23072269NAME: "module F0", DESCR: "Cisco ISR4431 Forwarding Processor"
PID: ISR4431/K9 , VID: , SN:
Router#show license all
License Store: Primary License Storage
StoreIndex: 0 Feature: ipbasek9 Version: 1.0
License Type: Permanent
License State: Active, In Use
License Count: Non-Counted
License Priority: Medium
License Store: Built-In License Storage
StoreIndex: 0 Feature: appxk9 Version: 1.0
License Type: EvalRightToUse
License State: Active, Not in Use, EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: None
StoreIndex: 1 Feature: uck9 Version: 1.0
License Type: EvalRightToUse
License State: Active, Not in Use, EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: None
StoreIndex: 2 Feature: securityk9 Version: 1.0
License Type: EvalRightToUse
License State: Active, Not in Use, EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: None
StoreIndex: 3 Feature: FoundationSuiteK9 Version: 1.0
License Type: EvalRightToUse
License State: Active, Not in Use, EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: None
StoreIndex: 4 Feature: AdvUCSuiteK9 Version: 1.0
License Type: EvalRightToUse
License State: Active, Not in Use, EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: None
StoreIndex: 5 Feature: cme-srst Version: 1.0
License Type: EvalRightToUse
License State: Active, Not in Use, EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: 0/0 (In-use/Violation)
License Priority: None
StoreIndex: 6 Feature: throughput Version: 1.0
License Type: EvalRightToUse
License State: Active, Not in Use, EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: NoneRouter#show ver
Cisco IOS XE Software, Version 16.09.04
Cisco IOS Software [Fuji], ISR Software (X86_64_LINUX_IOSD-UNIVERSALK9-M), Version 16.9.4, RELEASE SOFTWARE (fc2)
Technical Support: (c) 1986-2019 by Cisco Systems, Inc.
Compiled Thu 22-Aug-19 18:09 by mcpre
Cisco IOS-XE software, Copyright (c) 2005-2019 by cisco Systems, Inc.
All rights reserved. Certain components of Cisco IOS-XE software are
licensed under the GNU General Public License ("GPL") Version 2.0. The
software code licensed under GPL Version 2.0 is free software that comes
with ABSOLUTELY NO WARRANTY. You can redistribute and/or modify such
GPL code under the terms of GPL Version 2.0. For more details, see the
documentation or "License Notice" file accompanying the IOS-XE software,
or the applicable URL provided on the flyer accompanying the IOS-XE
software.
ROM: IOS-XE ROMMONRouter uptime is 3 minutes
Uptime for this control processor is 5 minutes
System returned to ROM by Reload Command
System image file is reload reason: Reload CommandThis product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.A summary of U.S. laws governing Cisco cryptographic products may be found at:If you require further assistance please contact us by sending email to
(email)Suite License Information for Suite Current Type Suite Next None None None None Package License Technology-package Technology-package
Current Type Next None None None
uck9 None None None
securityk9 None None None
ipbase ipbasek9 Permanent ipbasek9The current throughput level is 500000 kbps
Smart Licensing Status: Smart Licensing is DISABLEDcisco ISR4431/K9 (1RU) processor with 1784318K/6147K bytes of memory.
Processor board ID FJC2309A0XB
4 Gigabit Ethernet interfaces
32768K bytes of non-volatile configuration memory.
4194304K bytes of physical memory.
6598655K bytes of flash memory at bootflash:.
0K bytes of WebUI ODM Files at webui:.Configuration register is 0x2102
