Corning CCH-UM12-05-93Q Plug & Play Module, 12 Fiber, Shuttered LC to MTP, Multimode 50um OM4

Description:

Corning Plug & Play™ Universal Module, Low-Loss, 12 F, Shuttered LC to MTP®, 50 µm multimode (OM4)Part Number: CCH-UM12-05-93QThe Plug & Play™ modules provide the interface between the MTP® on the trunk and the LC duplex jumpers that will then connect directly into the electronics. The LC duplex adapters feature hinged VFL-compatible shutters that move up and out of the way when the connector is inserted. Specially designed indents in the shutters ensure that the end faces of the connectors are never touched. These shutters replace the standard dust caps that typically once removed are never replaced, exposing the interior end faces to dust particles and possible Specifications

Product Number CCH-UM12-05-93Q

EAN Code 4042673386674

Product Type Panels and Modules

Fiber Category 50 µm MM (OM4)

Application Data Center LAN/SAN

Standards

RoHS Free of hazardous substances according to RoHS 2011/65/EU

Design

Fiber Count 12

Adapter Type Back MTP®

Adapter Color Back Aqua

Adapter Color Front Aqua

Adapter Type Front Shuttered LC

Housing Type CCH

Number of Adapters per Panel 6

Cable Design

Fiber Count 12

Optical Specification - Hardware

Insertion Loss 0.5 dB

Fiber Category 50 µm MM (OM4)
