Dell 4H1RX Micron MTFDDAK3T8TDT-1AW16ABDA 5300 MAX 3.84TB 2 6Gbps MU SATA SSD
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.
Dell 4H1RX Micron MTFDDAK3T8TDT-1AW16ABDA 5300 MAX 3.84TB 2 6Gbps MU SATA SSD
Price: US $1304.99
Dell 4H1RX Micron MTFDDAK3T8TDT-1AW16ABDA 5300 MAX 3.84TB 2.5" 6Gbps 3D NAND QLC Mixed Use SATA Solid State Drive - RefurbishedRefurbished

Dell 4H1RX  Micron MTFDDAK3T8TDT-1AW16ABDA 5300 MAX 3.84TB 2.5 6Gbps 3D NAND QLC Mixed Use SATA Solid State Drive - Refurbished

The SSD is designed to use the SATA interface efficiently during both READs and WRITEs while delivering bandwidth-focused performance. SSD technology enables enhanced boot times, faster application load times, reduced power consumption and extended reliability.

Micron 5300 SSD with TCG Opal encryption: These SEDs are well suited for server and storage platform boot-up. A TCG Opal drive provides pre-boot authentication (PBA) for secure server password entry before the OS boot process 3D TLC NAND Flash

  • Three performance/endurance Enterprise compliant self-encrypting drive (SED)
  • SATA 6 Gb/s interface
  • ATA modes supported
    • PIO mode 3, 4
    • Multiword DMA mode 0, 1, 2
    • Ultra DMA mode 0, 1, 2, 3, 4, 5, 6
  • 512-byte sector size support
  • Hot-plug capable
  • Native command queuing support with 32-command slot support
  • ATA-8 ACS-3 revision 5 command set compliant
  • ATA security feature command set and password login support
  • Security erase command set: fast and secure erase
  • Performance (steady state)
    • Sequential 128KB read: Up to 540 MB/s
    • Sequential 128KB write: Up to 520 MB/s
    • Random 4KB read: Up to 95,000 IOPS
    • Random 4KB write: Up to 75,000 IOPS
  • Quality of Service
    • Read/Write (99.9%): 200µs/300µs
    • Read/Write (99.999%): : Total bytes written (TBW)
      • Up to 3.0 million device hours
      • Static and dynamic wear leveling
      • Uncorrectable bit error rate (UBER): <1 sector per 10e17 bits read
      • End-to-end data protection
      • Enhanced power-loss data protection with data protection capacitor analysis, and reporting technology (SMART) command set
      • Capacity (unformatted): 240GB, 480GB, 960GB, 1920GB, 3840GB, x 7.0mm form factor
    • RoHS-compliant package
    • Secure field-upgradeable firmware with digitally signed firmware image
    • Power consumption:
      • <3.9W(TYP, 5V only)
    • Operating temperature
      • Commercial (0°C to 3.0 million Idle Average 1.5W Flash Type 3D TLC Dimensions (W x L x H) 69.85mm x 100.45mm x 7.00mm

        Micron 5300 MAXModel NumberMTFDDAK3T8TDT-1AW1ZABDATechnical Enterprise SSDModel5300 MAXCapacity3.84TB / 3840GBEncryption DetailsTcg-opalForm Factor2.5in (6.4cm)Sequential Read (128KB transfer)540
        3.0WSequential Write (128KB transfer)520
        3.9WRandom Read (4KB transfer)95,000Random Write (4KB transfer)34,000Random 70/30 R/W (4KB transfer)60,000Read latency (99.9%)250µsWrite latency (99.9%)200µsRead latency (99.999%)700µsWrite latency (99.999%)500µsDrive Lifetime (Total Bytes Written)24,528TB DWPD: 3-5
         Voltage temperatureMin: 0°C
        Max: 70°CNon Operating temperatureMin: -40°C
        Max: 85°CRate of temperature changeMax: 20°C/hourRelative humidity (non-condensing)Min: 5%
        Max: 95%Min Operating Temperature32°FNon-operating shock1500G/0.5msNon-operating vibration5–800Hz at 3.13 GrmsUncorrectable Bit Error Rate<1 sector per 10e17 bitsMTTF3.0 millionIdle Average1.5WFlash Type3D TLCDimensions (W x L x H)69.85mm x 100.45mm x Part Numbers: 4H1RX 04H1RX MTFDDAK3T8TDT-1AW1ZABDA MTFDDAK3T8TDT-1AW16ABDA
