The EKWB EK-Quantum Kinetic FLT 240 DDC PWM D-RGB – Plexi is a high-quality water cooling pump designed for computer systems. With a fan diameter of 120mm and made of transparent plexi material, this pump features a clear color design that is both aesthetically pleasing and functional. It is powered by SATA Power and a 4-Pin PWM fan connector, making it easy to install and use. Made in Slovenia by EKWB, this pump is a reliable choice for cooling systems requiring efficient and effective water circulation.

Technical specifications:

- Size (HxWxT): 245x120x58mm (with mounting system)
- Capacity: ~265ml
-D-RGB connector 3-pin 5V digital LED header (Pinout: +5V, D, Blocked, Ground)

Pump electrical and mechanical properties:

- Motor: Electronically commuted ball bearing motor
- Rated voltage: 12 V DC
- Power consumption: 20W
- Maximum head pressure: up to 5.2m
- Maximum flow rate: up to 1000 L/h
- Maximum liquid temperature: 60 °C
- Materials: Stainless steel, PPS-GF40, EPDM O-rings, Aluminium oxide, hard coal
- Power connector: SATA power and 4-Pin PWM FAN connector

Operational regime:

- PWM duty cycle: ~ 20-100%
- Default behavior: Runs at 100% duty cycle when no PWM response signal is present
