BrandFortinetProduct LineFortinet BrandFortinetProcessor TypeFortiASIC SP5
Network & CommunicationConnectivity TechnologyWiredData Link Protocols10 Gigabit Ethernet, Bluetooth LE, Ethernet, Fast Ethernet, Gigabit EthernetFeaturesCAPWAP support, High Availability, Reset button, SSL inspection, Trusted Platform Module (TPM), VPN supportForm FactorRack-mountableNetwork StandardHTTP, HTTPs, IPSec, IPv6, TCP/IP, UDP/IPProduct TypeSecurity applianceRemote ManagementHTTP, HTTPSStatus IndicatorsAlarm, HA, Power, StatusWireless LANBluetooth LE
ConnectivityInterface Provided1 x 1000Base-T (HA) - RJ-45, 1 x 1000Base-T (management) - RJ-45, 1 x console - RJ-45, 1 x USB 3.0 - Type A, 16 x 1000Base-T - RJ-45, 4 x 10GBase-X (FortiLink) - SFP+, 8 x 1000Base-X - SFP
PowerFrequency50/60 hertzPower Consumption Operational38 wattPower Supplies Installed2Redundant Power SupplyYesRequired VoltageAC 100-120 volt
SoftwareOperating SystemFortiOS
Technical InformationEncryption256-bit AES, 256-bit SHA, SSL, TLS 1.3Max Operating Temperature104 degree FahrenheitMin Operating Temperature32 degree FahrenheitOperating Humidity20 - 90% (non-condensing)
Product InformationAirflow DirectionSide to back airflowCapacityClient to gateway IPSec VPN tunnels: 16000, Concurrent sessions: 3000000, Concurrent SSL VPN users: 500, Firewall policies: 10000, Gateway to gateway IPSec VPN Tunnels: 2000, Maximum number of switches: 32, Maximum virtual domains: 10, New sessions per second: 140000, Number of FortiAP devices (tunnel): 64, Number of FortiAP devices: 128, Number of FortiToken devices: 5000, SSL inspection concurrent sessions: 315000, SSL inspection CPS: 2100, Virtual domains: 10Device TypeInternal power supplyPackaged Quantity1Service ActivationNoNetwork DeviceApplication control throughput (HTTP 64K): 6.7 Gbps, CAPWAP Throughput (HTTP 64K): 35 Gbps, Firewall latency (64-byte UDP): 3.17 µs, Firewall throughput (1518-byte UDP): 39 Gbps, Firewall throughput (512-byte UDP): 39 Gbps, Firewall throughput (64-byte UDP): 28 Gbps, Firewall throughput: 42 Mpps, IPS throughput (enterprise traffic mix): 5.3 Gbps, NGFW throughput: 3.1 Gbps, SSL inspection throughput: 3 Gbps, Threat protection throughput: 2.8 Gbps, VPN throughput (512-bit IPSec): 35 Gbps, VPN throughput (SSL): 1.5 Gbps
Included ItemsCables1 x network cable, 2 x power cableIncluded Accessories2 mounting brackets, 4 rubber feet, 8 screws
Dimensions & WeightHeight1.7 inchHeight (Rack Units)1Weight12.17 lbsWidth17 inchDepth10 inch
Physical CharacteristicsColor CategoryWhite
Certifications & ListingsCompliant StandardsBSMI, CB, cUL, FCC Part 15 B Class A, RCM, UL, USGv6, VCCIENERGY STAR CertifiedNo
