GIGABYTE X299X AORUS MASTER, LGA 2066, Intel Motherboard
Motherboard chips
Main chipset
Intel X299X
Chipset description
Powered by Intel X299 chipset
Display chips
CPU built-in display chip (CPU support required)
Audio chips
Integrated Realtek ALC1220 VB audio chip
Processor specifications
CPU type
Core i9 X-Series, Core i7 7800X and above
CPU socket
LGA 2066
Memory specifications
Memory type
8×DDR4 DIMM
Maximum memory capacity
Core X-series 48-channel processor: 256GB Core X-series 44-channel/28-channel processor: 128GB
Memory description
Core X-series 48-channel processor: supports dual-channel DDR4 2933/2666/2400/2133MHz memory
Core X-series 44-channel/28-channel processor: supports dual-channel DDR4 2666/2400/2133MHz memory
Storage expansion
PCI-E standard
PCI-E 3.0
PCI-E slots
Core X-series 48-lane processors: 2 × PCIe x16 slots, running at x16 2× PCI-E x16 slots, running at X8
Core X-series 44-lane processors:
2 × PCI-E x16 slots, running at X16 1×PCIe x16 slots, running on X8
1×PCIe x16 slots, running on X4
Storage interfaces
2× M.2 interface, 8× SATA III interface
I/O interface
USB interface
1× USB Type-C port, support USB3.2 Gen2 2× USB3.2 Gen1 header
3× USB2.0 connector 1× USB Type-C port, support USB3.2 Gen2
1× USB3.2 Gen2 Type-A port (red)
6×
USB3.2 Gen1 port 2 × USB
2.0 port
Power connector
Two 8-pin, one 24-pin power connectors
Other interfaces
1× Thunderbolt port, 1 ×Gigabit LAN port, 1×5GbE LAN port, 5 × audio port, 1 × optical port
Plate type
Motherboard form factor
E-ATX form factor
Dimensions
30.5×26.9cm
Software management
BIOS performance
2 x 128 Mbit flash AMI
with licensed UEFI BIOS
SUPPORTS DualBIOS Plug & Play 1.0a, DMI 2.7, WfM 2.0, SM BIOS
2.7, ACPI 5.0
Other parameters
Multi-graphics technology
Supports AMD CrossFireX technology with support for NVIDIA SLI technology
Power supply mode
12+1 phase
RAID function
RAID 0, 1, 5, 10 is supported
Hardware monitoring
Voltage Detection, Temperature Detection, Fan Speed Detection, Water Cooling Flow Detection, Overheating Warning, Fan Failure Warning, Fan Speed Control, Noise Detection
Wireless capability
Wireless: Support 802.11 a/b/g/n/ac/ax WiFi standard, support 2.4/5GHz dual band
Bluetooth
Bluetooth 5.0 is supported
Other features:
