CPU AMD AM5 Socket, Supports:
- AMD Ryzen 9000 Series Processors
- AMD Ryzen 8000 Series Processors
- AMD Ryzen 7000 Series Processors
(Please visit GIGABYTE website for the supported CPU list) Chipset AMD B850 Memory - 4x DDR5 DIMM Slots, supporting up to 256 GB (64 GB per slot)
- Supports Dual Channel Memory Technology
- Supports DDR5 8200(O.C.) / 8000(O.C.) / ... / 4800 MT/s
- Supports non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16
- Supports AMD EXPO and Intel XMP Memory Modules
(Supported speed and capacity may vary by CPU and memory module; please check the memory support list on GIGABYTE's website.) Display Integrated in supported CPUs:
- 1x DP port, supporting up to 3840x2160@144 Hz (DP 1.4 with HDR)
- 1x Front Panel HDMI port, supporting up to 1920x1080@30 Hz (HDMI 1.4)
(Supported display specifications depend on the CPU used.) Audio - Integrated Realtek Audio Codec
- Supports High Definition Audio
- Supports 2/4/5.1/7.1-channel
- Supports S/PDIF Output Networking Wired:
- Integrated Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless:
- Integrated Realtek Wi-Fi 7 RTL8922AE
- Supports 802.11a/b/g/n/ac/ax/be, 2.4/5/6 GHz bands
- Supports Bluetooth 5.4
(Actual transmission speed may vary depending on the environment and equipment.) Expansion Slots -1x PCIe x16 Slot (PCIEX16)from CPU:
Ryzen 9000/7000: PCIe 5.0 x16
Ryzen 8000 Phoenix 1: PCIe 4.0 x8
Ryzen 8000 Phoenix 2: PCIe 4.0 x4
-1x PCIe x16 Slot (PCIEX4)from Chipset: PCIe 3.0 x4 Storage M.2 Slots:
-M2A_CPU:1x M.2 (Key M), supports 25110/22110/2280. From CPU:
Ryzen 9000/7000: PCIe 5.0 x4/x2
Ryzen 8000: PCIe 4.0 x4/x2
-M2B_CPU:1x M.2 (Key M), supports 22110/2280. From CPU:
Ryzen 9000/7000: PCIe 4.0 x4/x2
Ryzen 8000: PCIe 4.0 x4/x2
SATA Ports:
- 4x SATA 3.0 ports
RAID Support:
- NVMe SSD: RAID 0, RAID 1, RAID 5, RAID 10 (RAID 5 for Ryzen 9000 only)
- SATA HDD: RAID 0, RAID 1, RAID 10 USB Rear I/O Panel:
- 1x USB Type-C® (USB 3.2 Gen 2)
- 2x USB Type-A (Red, USB 3.2 Gen 2)
- 5x USB Type-A (USB 3.2 Gen 1)
- 4x USB Type-A (USB 2.0/1.1)
Internal Headers:
- 1x USB Type-C® header (USB 3.2 Gen 2x2)
- 1x USB 3.2 Gen 1 header (supports 2 ports)
- 2x USB 2.0/1.1 headers (support 4 ports) Internal Headers & Connectors - 1x 24-pin ATX main power connector
- 1x 8-pin CPU power connector
- 1x CPU fan header
- 1x CPU fan/water cooling pump header
- 3x system fan headers
- 1x system fan/water cooling pump header
- 3x Addressable RGB LED strip headers (Gen2)
- 1x RGB LED strip header
- 1x Front Panel Audio header
- 1x Front Panel header
- 1x TPM module header
- 1x HDMI header (CPU-dependent)
- 1x System Reset Button
- System Reset jumper
- Clear CMOS jumper Rear I/O Panel - 1x DP port (CPU-dependent)
- 1x Q-Flash Plus button
- 4x USB 2.0/1.1 ports
- 5x USB 3.2 Gen 1 ports
- 2x USB 3.2 Gen 2 Type-A ports (Red)
- 1x USB Type-C® port (USB 3.2 Gen 2)
- 1x RJ-45 LAN port
- 2x Wi-Fi Antenna ports (2T2R)
- 2x Audio jacks
- 1x S/PDIF Optical Out
