FULLY MODULAR DESIGN
All the black flat cables are modular design. Installingonly the cables you need to reduce clutter, to increase the airflow and toimprove the chassis thermal performance.
80 PLUS GOLD CERTIFIED
80 Plus Gold certified ensures to deliver 90% efficiency at50% load. The better power efficiency leads to less power waste, less heat andless fan noise. And with the support of Intel processors, it will save moreenergy and more money.
HIGH QUALITY JAPANESE CAPACITORS
The main capacitors are high quality Japanese capacitors, toproduce the efficient performance and to ensure the longer reliability.
The life of the main capacitor is over 20 years
(Environment 25°C)
120MM SMART HYDRAULIC BEARING (HYB) FAN
The fan speed is adjusted according to the automatic powerdetection and will stop when the system is idle or under low load (less than20% load). The Hydraulic Bearing fan provides longer and more stable life time.
The curve is for reference only. Please refer to the colorbox for actual curve.
The life of the Hydraulic Bearing fan is more than 4 years
SINGLE +12V RAIL
Single +12V rail provides the best power output, stabilityand compatibility for the hardware. It provides the easiest way to install thepower cable. And it is the best design for overclocking.
Model
GP-P850GM
Type
Intel Form Factor ATX 12V v2.31
PFC
Active PFC (>0.9 typical)
Input Voltage
100-240 Vac (full range)
Input Current
12-6 A
Input Frequency
60-50 Hz
Output Capacity
850W
Dimension
150 x 140 x 86 mm
Fan Type
120mm Hydraulic Bearing ( HYB ) fan
80 PLUS
Gold
Efficiency
90% at typical load
MTBF
>100,000 hours
Protection
Power Good Signal
100-500ms
Hold Up Time
>16ms
Cable Type
Flat, All black
Connectors
ATX/MB 20+4 Pin x 1 : 610mm*1
CPU/EPS 4+4 Pin x 2 : 600mm*2
PCI-e 6+2 Pin x 4 : 600mm+150mm*2
SATA x 8 : 600mm+150mm+150mm+150mm*2 :
4 Pin Peripheral x 3 + 4-Pin floppy x 1 :
