****Listing for one each item only****
HPE PN/ JC106A
HPE SPN/ JC106-61101
Note: JC106A is same as JG296A
HP 5820-14XG-SFP+ Switch with 2 Slots (HP RENEW) included with 1x JC087A HP ProCurve A58x01AF AC Power Supply HPE RENEW
Condition : HPE RENEW .
HP 5820 Switch Series The HP 5820 Switch Series are advanced flex-chassis switches.Fixed Port L3 Managed Ethernet SwitchesQuickSpecs
HP 5820-14XG-SFP+ Switch with 2 Slots(JC106A) HP 5820-14XG-SFP+ Switch with 2 Slots (JC106A)HP 5820-24XG-SFP+ Switch (JC102A)HP 5820AF-24XG Switch (JG219A)Ports14 SFP+ 10GbE ports
Duplex: full only
2 extended module slots
1 open module slot
4 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
1 RJ-45 serial console port
Supports a maximum of 14 SFP+ ports plus 8 8/4/2 Gbps Fibre Channel SFP+ ports, with optional module
24 SFP+ 10GbE ports
Duplex: full only
4 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
1 RJ-45 serial console port
Supports a maximum of 24 SFP+ ports plus 4 autosensing 10/100/1000 ports
24 fixed 1000/10000 SFP+ ports
2 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
1 RJ-45 serial console port
1 RJ-45 out-of-band management port
1 USB 2.0
Power supplies2 power supply slots
1 minimum power supply required (ordered separately)
2 power supply slots
1 minimum power supply required (ordered separately)
2 power supply slots
1 minimum power supply required (ordered separately)
Fan trayincludes: 1 x JC096Aincludes: 1 x JC098A2 fan tray slotsPhysical characteristics17.32(w) x 18.39(d) x 3.39(h) in (43.99 x 46.7 x 8.61 cm) (2U height)17.32(w) x 16.81(d) x 1.73(h) in (44.0 x 42.7 x 4.4 cm) (1U height)25.98(w) x 17.32(d) x 1.72(h) in (65.99 x 43.99 x 4.37 cm) (1U height)Weight33.29 lb (15.1 kg)18.74 lb (8.5 kg)22.05 lb (10 kg), Fully loadedMemory and processor1024 MB SDRAM, 512 MB flash; packet buffer size: 2 MB1024 MB SDRAM, 512 MB flash; packet buffer size: 2 MB1024 MB flash, 512 MB SDRAM; packet buffer size: 2 MBPerformanceLatency2.02 µs (Cut Through), 2.02 µs (Store and Forward) (64-byte packets)2.02 µs (Cut Through), 2.02 µs (Store and Forward) (64-byte packets)3 µs (64-byte packets)Throughputup to 363 million pps (64-byte packets)up to 363 million pps (64-byte packets)360 million ppsRouting/Switching capacity488 Gbps488 Gbps484 GbpsRouting table size12000 entries (IPv4)12000 entries (IPv4)12000 entries (IPv4)MAC address table size32000 entries32000 entries32000 entriesEnvironmentOperating temperature32°F to 113°F (0°C to 45°C)32°F to 113°F (0°C to 45°C)32°F to 113°F (0°C to 45°C)Operating relative humidity10% to 90%, noncondensing10% to 90%, noncondensing10% to 90%, noncondensingAcousticLow-speed fan: 44.3 dB, High-speed fan: 54.1 dBLow-speed fan: 48.4 dB, High-speed fan: 59.7 dBLow-speed fan: 60.1 dB, High-speed fan: 69.9 dBElectrical characteristicsFrequency50/60 Hz50/60 Hz50/60 HzMaximum heat dissipation836 BTU/hr (881.98 kJ/hr)631 BTU/hr (665.71 kJ/hr)607 BTU/hr (640.39 kJ/hr)Voltage100-120/200-240 VAC100-120/200-240 VAC100-120/200-240 VACDC voltage300 W DC: –48 VDC to –60 VDC300 W DC: –48 VDC to –60 VDC650W DC: -36 VDC to -72 VDCSafetyUL 60950-1EN 60825-1 Safety of Laser Products-Part 1EN 60825-2 Safety of Laser Products-Part 2IEC 60950-1CAN/CSA-C22.2 No. 60950-1AnatelULARGOSTEN 60950-1/A11FDA 21 CFR Subchapter JNOMROHS ComplianceUL 60950-1EN 60825-1 Safety of Laser Products-Part 1EN 60825-2 Safety of Laser Products-Part 2IEC 60950-1CAN/CSA-C22.2 No. 60950-1AnatelULARGOSTEN 60950-1/A11FDA 21 CFR Subchapter JNOMROHS ComplianceUL 60950-1EN 60825-1 Safety of Laser Products-Part 1EN 60825-2 Safety of Laser Products-Part 2IEC 60950-1CAN/CSA-C22.2 No. 60950-1AnatelULARGOSTEN 60950-1/A11FDA 21 CFR Subchapter JNOMROHS ComplianceNotesThe customer must order a power supply, as the device does not come with a PSU. At least one JC087A or JC090A is required.The customer must order a power supply, as the devicedoes not come with a PSU. At least one JC087A orJC090A is required.The customer must order power supply, as the device does not come with a PSU. At least one JC680A or JC681A is required.
Condition : HPE RENEW
NOTE:Lead time might take 4 weeks ,Please check detail lead time before purchasing if have rush order.
NOTE:Pictures may or may not be actual item, if need actual pictures or have any other question please send us message.
What is the HP Renew Program?The HP Renew Program offers an extensive portfolio of quality remanufactured products as a complement to new HP products. Through an extensive process of remanufacturing and recertification, HP Renew offers current, state of the art technology that is guaranteed to be the same quality and performance you would expect from new,What does "remanufactured" mean?Remanufactured products are models that have been returned to HP for a variety of reasons and then put through a rigorous refurbishment and testing process to bring them back to "same as new" condition and performance.HP Renew products are not to be confused with "used" or "second-hand" products. Instead, HP Renew offers high quality products that are completely remanufactured and retested by HP. All HP Renew products are Factory-Certified to be fully functional with performance standards equal to their factory new counterparts. The benefit: Factory-Certified HP technology at a lower cost and performance equal to equivalent new products,
