Brand new factory sealed.
GPON customer-premises equipment (CPE) with a built-in WiFi Guide
(5 x 5 x 1.3")
Weight
190 g (6.7 oz)
Enclosure Materials
UV-stabilized polycarbonate
Hardware
Networking Interface
(1) SC/APC, ITU-G.984 GPON WAN port
(4) GbE RJ45 LAN ports
WiFi 802.11n
Management
Ethernet In-Band
PON
Power Method
DC jack, 24V DC
24V passive PoE (Pins 4, 5+; 7, 8-)
Power Supply
Universal AC/DC adapter, 100–240V AC, 50/60 Hz, 24V/0.5A
Supported Voltage Range
10–30V DC (Passive PoE)
5V DC (Adapter)
Max. Power Consumption
7W
Normal Range of Optical Module
TX: 1.5 to 5 dBm
RX: -8 to -28 dBm
Total Non-Blocking Line Rate
Downstream: 2.5 Gbps
Upstream: 1.2 Gbps
Max. TX Power
2.4 GHz
20 dBm
MIMO
2.4 GHz
2 x 2
Throughput
2.4 GHz
300 Mbps
Antenna Gain
2.4 GHz
1 dBi
LEDs
PON Status
(3) Signal LEDs
All off: Bootup
1x red: Signal too low (< -28 db)
1x white: Signal low (>= -28 db)
2x white: Signal good (>= -25 db)
3x white: Signal strong (>= -11 db)
1x red + 2x white: Signal too strong (>= -8 db)
3x red: No signal
LEDs alternate between 3x red and a signal strength indicator: No authority
Ethernet
Steady white: Link up
Blinking white: Activity
Off: Link down
Power
White: On
Button
(1) Factory reset
Ambient Operating Temperature
-10 to 45° C (14 to 113° F)
Ambient Operating Humidity
10 to 90% IC, CE
NDAA Compliant
✓
Fiber
Optical Interface Nominal Bitrate
TX: 1310 nm
RX: 1490 nm
Line Code
Scrambled NRZ
Operating Wavelength
Downstream: 2.5 Gbps
Upstream: 1.2 Gbps
Max. Range
20 km
Software
Mode
ONU/ONT layer 2/3 Ethernet switch
Services
Web server, telnet, NAT, bridging and routing, firewall features, and application passthrough monitoring, alarms, and logs
Remote reset, remote reboot, remote firmware upgrade, VLAN support
Security
GEM port encryption
WiFi Standards
802.11 b/g/n
Wireless Security
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3, TKIP/AES)
Supported Data Rates
802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b
1, 2, 5.5, 11 Mbps
