Ubiquiti LTU‑Pro | Streakwave 📡 Ubiquiti LTU‑Pro
5 GHz PtMP Client with Advanced RF Performance
Designed for high-performance wireless backhaul in PtMP networks, optimized for use under a LTU-Rocket base station.
✅ Ideal For
- 🏢 Point-to-Multipoint (PtMP) client links with a LTU-Rocket as the base station.
- 🌐 High-throughput subscriber connections requiring stable throughput over distance.
- 🔒 Environments where advanced RF features, auto power and distance adjust, and encryption are important.
- 📶 Clients needing a sleek, weather-resistant, outdoor-rated device.
- 🧰 Installations requiring passive 24 V PoE and flexible mounting options.
📦 Product Overview & Specifications LTU‑Pro Specifications Overview ModelUbiquiti LTU‑Pro 5 GHz RolePtMP Client (works under LTU-Rocket base) Processor / FeaturesAdvanced RF, auto distance adjustment, auto power adjustment, airView® diagnostics Maximum Throughput900+ Mbps (firmware v2.3.0 and later) :contentReference[oaicite:1]{index=1} Networking Interface(1) Gigabit RJ45 Power MethodPassive PoE (2‑pair: 4,5+ and 7,8‑) :contentReference[oaicite:2]{index=2} Included Power Supply24V, 0.5 A Gigabit PoE Adapter :contentReference[oaicite:3]{index=3} Supported Voltage Range22‑27 V DC :contentReference[oaicite:4]{index=4} Max Power Consumption9 W :contentReference[oaicite:5]{index=5} ESD/EMP Protection±24 kV air/contact :contentReference[oaicite:6]{index=6} Operating Temp−40 to 60 °C (−40 to 140 °F) :contentReference[oaicite:7]{index=7} Humidity10% to 90% noncondensing :contentReference[oaicite:8]{index=8} Dimensions316.5 × 316.5 × 174.3 mm (12.5 × 12.5 × 6.9 in) :contentReference[oaicite:9]{index=9} Weight1.3 kg (2.9 lb) :contentReference[oaicite:10]{index=10} Enclosure MaterialUV-stabilized polycarbonate :contentReference[oaicite:11]{index=11} Wind Load / Survivability150 N at 200 km/h; survivability 200 km/h :contentReference[oaicite:12]{index=12} RF & AntennaAntenna gain: 24 dBi; beamwidth: 14°; front-to-back ratio: 27 dB; sidelobe level: –10 dB :contentReference[oaicite:13]{index=13} TX Power / ChannelMax TX: 22 dBm per chain; channel bandwidth: up to 100 MHz :contentReference[oaicite:14]{index=14} Software Modes & FeaturesPtMP CPE, PtP (experimental), auto distance & power, encryption WPA2‑AES, bridge/router mode, SNMP, SSH, remote log, alignment tools :contentReference[oaicite:15]{index=15} Management InterfaceBluetooth setup through UISP App, Web UI, remote discovery, remote logging :contentReference[oaicite:16]{index=16} Certifications & ComplianceCE, FCC, IC; NDAA Compliant :contentReference[oaicite:17]{index=17} 🚀 Why Choose LTU‑Pro?
- Optimized for point-to-multipoint networks with a LTU‑Rocket base station.
- High throughput of 900+ Mbps in real-world scenarios (firmware v2.3+).
- Automatic adjustments for power and distance ensure stable links.
- Compact, outdoor-rated design with strong wind survivability.
- Simple setup with passive PoE and Bluetooth or web UI configuration.
