Used but working! nice compact, single slot 2GB graphics card.
The PNY NVIDIA Quadro 4000 Graphics Card is a high-performance unit with 2GB of GDDR5 memory and a 256-bit interface. It features DisplayPort and DVI connectors, as well as support for multiple monitors. Designed for professional use, this NVIDIA Quadro 4000 graphics card is compatible with a PCI Express 2.0 x16 slot and utilizes a fan with heatsink cooling system. With DirectX 11 API support, this graphics card delivers exceptional graphics performance for demanding applications in fields such as graphic design, animation, and video editing.
The Quadro 4000 was an enthusiast-class professional graphics card by NVIDIA, launched on November 2nd, 2010. Built on the 40 nm process, and based on the GF100 graphics processor, in its GF100-825-A3 variant, the card supports DirectX 12. The GF100 graphics processor is a large chip with a die area of 529 mm² and 3,100 million transistors. Unlike the fully unlocked GeForce GTX 480 Core 512, which uses the same GPU but has all 512 shaders enabled, NVIDIA has disabled some shading units on the Quadro 4000 to reach the product's target shader count. It features 256 shading units, 32 texture mapping units, and 32 ROPs. NVIDIA has paired 2,048 MB GDDR5 memory with the Quadro 4000, which are connected using a 256-bit memory interface. The GPU is operating at a frequency of 475 MHz, memory is running at 702 MHz (2.8 Gbps effective).
Being a single-slot card, the NVIDIA Quadro 4000 draws power from 1x 6-pin power connector, with power draw rated at 142 W maximum. Display outputs include: 1x DVI, 2x DisplayPort. Quadro 4000 is connected to the rest of the system using a PCI-Express 2.0 x16 interface. The card's dimensions are 241 mm x 111 mm x 20 mm, and it features a single-slot cooling solution. Its price at launch was 1199 US Dollars.Graphics ProcessorGPU NameGF100GPU TypeCLN40G CMOSProcess Size40 nmTransistors3,100 millionDensity5.9M / mm²Die Size529 mm²Chip PackageFCBGA-1980Package Size42.5 mm × 42.5 mmGraphics CardRelease DateNov 2nd, 2010GenerationQuadro Fermi
(x000)PredecessorQuadro FX Tesla ReferralSuccessorQuadro KeplerProductionEnd-of-lifeDriver SupportLegacyLaunch Price1,199 USDBus InterfacePCIe 2.0 x16Reviews26 in our database
