Description:

The NetKey Flat Punchdown Keystone Patch Panel terminates 4-pair, 22–26 AWG, 100-ohm twisted pair cable. These Cat 5e patch panels mount to 19" and 23" racks and incudes 48 ports. The RJ45 interface provides a quick plug and play connection to RJ45 patch cords. This punchdown patch panel is 2 RU, made of steel and is black.Specifications:

• Product Type Punchdown
• Termination Style Punchdown
• Patch Panel Style Flat
• Performance Level Category 5e
• Material CRS
• Wiring Scheme T568A/T568B
• Number of Ports 48
• Module Type RJ45
• Number of Rack Units 2
• Overall Width (In.) 19
• Overall Width (mm) 482.6
• Sub Brand NetKey®
• Overall Depth (In.) 1.17
• Overall Depth (mm) 29.7
• Overall Height (In.) 3.47
• Overall Height (mm) 88.1
• Identification Type Adhesive Label
• Color Black
• Standards Met Exceeds ANSI/TIA-568-C.2 Category 5e and ISO 11801 Class D channel requirements at swept frequencies up to 100 MHz. Meets ANSI/TIA-568-C.2 and ISO 11801 Category 5e component requirements at swept frequencies up to 100 MHz.Complies with ANSI/TIA-1096A (formerly FCC Part 68), Meets IEC 60603-7, Supports IEEE 802.3af/802.3at and proposed 802.3bt type 3 and type 4 PoE applications, UL 1863 approved, RoHS Compliant
• Maximum Operating Temperature (°C) 65
• Maximum Operating Temperature (°F) 149
• Minimum Operating Temperature (°C) -10
• Minimum Operating Temperature (°F) -14
• Overall Length (In.) 1.17
• Overall Length (mm) 29.7
