Seagate Hard Drive PCB Controller Board 100809471 Rev A – Donor Logic Board for
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.
Seagate Hard Drive PCB Controller Board 100809471 Rev A – Donor Logic Board for
Price: US $39.99

This listing is for a Seagate HDD PCB (Printed Circuit Board), board number 100809471 Rev A.

  • Board Number: 100809471 Rev A (printed on PCB)

  • Date Code: B1943 (stamped on connector housing)

  • Controller Chips:

    • Marvell 88I1164-ND82

    • Nanya NT5TU64M16HZ-AC

    • Smooth 780H0 VS H (Motor Controller, data-start="1674" data-end="1711">

      Connectors: SATA power + data

    • PCB Color: Blue

    Important Notes:

    • This is a logic board only, no drive included.

    • Ideal as a donor board for repair or recovery.

    • For proper operation, the BIOS/ROM chip may need to be transferred from your original PCB.
