Supermicro SYS-2028U-E1CNR4T+ Barebones Server X10DRU-i+ NEW IN STOCK 5 Yr Wty
SpecificationsProduct SKUsSYS-2028U-E1CNR4T+

• SuperServer 2028U-E1CNR4T+ (Black)

Motherboard
Super X10DRU-i+Processor/CacheCPU

• Intel® Xeon® processor E5-2600v4†/ v3 family (up to 160W TDP)*

• Dual Socket R3 (LGA 2011)

Cores / Cache

• Up to22 Cores†/ Up to55MB†Cache

System Bus

• QPI up to 9.6 GT/s

Note†BIOS version 2.0 or above is requiredNote* Please contact Supermicro Technical Support for additional information about frequency optimized CPUs and specialized system optimization.
System MemoryMemory Capacity

• 24x 288-pin DDR4 DIMM slots
• Up to 3TB†ECC 3DS LRDIMM, 1.5TB ECC RDIMM/LRDIMM

Memory Type

• 2400†/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit
• 2666/2400 ECC DDR4 NVDIMM

DIMM Sizes

• RDIMM: 32GB, 16GB, 8GB, 4GB
• LRDIMM: 64GB, 32GB
• 3DS LRDIMM: 128GB
• NVDIMM: 16GB

Memory Voltage

• 1.2 V

Error Detection

• Corrects single-bit errors

On-Board DevicesChipset

• Intel® C612 chipset

SATA

• SATA3 (6Gbps) with RAID 0, 1, 5, 10

IPMI

• Support for Intelligent Platform Management Interface v.2.0
• IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
• ASPEED AST2400 BMC

Network Connectivity

• 4x 10GBase-T ports viaAOC-2URN4-i4XT
• Intel® X540 10GBase-T
• 1 Realtek RTL8211E PHY (dedicated IPMI)

Graphics

• ASPEED AST2400 BMC

Input / OutputSAS

• 24 SAS3 ports support via expander and storage Add-on Cards
• One of the following storage Add-on cards required:

  AOC-S3108-H8iR (12Gbps SAS3/RAID 0, 1, 5, 6, 10, 50, 60, 2GB DDR3 cache, PCI-E Gen3)

  AOC-S3008L-L8i (12Gbps SAS3/RAID 0,1 and 10, PCI-E Gen3)

  AOC-S3008L-L8e (12Gbps SAS3/HBA, PCI-E Gen3)

NVMe

• 4 NVMe ports

LAN

• 4 RJ45 10GBase-T LAN ports
• 1 RJ45 Dedicated IPMI LAN port

USB

• 5 USB 3.0 ports
  (2 rear, 2 onboard header, 1 Type A)

Video

• 1 VGA Connector

Serial Port / Header

• 1 Serial header

DOM

• 2 SuperDOM(Disk on Module) ports

System BIOSBIOS Type

• 128Mb SPI Flash EEPROM with AMI BIOS

BIOS Features

• Plug and Play (PnP)
• APM 1.2
• PCI 2.3
• ACPI 1.0 / 2.0 / 3.0 / 4.0
• USB Keyboard support
• SMBIOS 2.7.1
• UEFI 2.3.1

ManagementSoftware

• SuperDoctor® 5
• Intel® Node Manager 3.0
• Watch Dog
• NMI
• SUMandSSM
• Optional IPMI 1.5 / 2.0

Power Configurations

• ACPI Power Management
• Power-on mode for AC power recovery

ChassisForm Factor

• 2U Rackmount

Model

• 17.2" (437mm)

Height

• 3.5" (89mm)

Depth

• 27.76" (705.3mm)

Weight

• Net Weight: 36 lbs (16.4 kg)
• Gross Weight: 72 lbs (32.7 kg)

Available Colors

• Black

Front PanelButtons

• Power On/Off button
• System Reset button

LEDs

• Power status LED
• HDD activity LED
• 2 Network activity LEDs
• System information (overheat/UID) LED

Expansion SlotsPCI-Express

• Up to 6 PCI-E 3.0 x8 slots
  (4 FH, 10.5" L, 1 LP, 1 Internal LP)


(Both CPUs need to be installed for full access to PCI-E slots and onboard controllers. See manual block diagram andAOC Supportfor details.)

Drive BaysHot-swap

• 24 Hot-swap 2.5" drive bays
• Default 4 NVMe ports
• 24 SAS3 ports support via Expander and AOC


Note: Storage Add-on card is required

System CoolingFans

• 4 heavy duty 8cm PWM fans

Shroud

• 1 Air Shroud

Power Supply1000W Redundant Power Supplies with PMBusTotal Output Power

• 800W: 100 – 127Vac
• 1000W: 200 – 240Vac
• 1000W: 200 – 240Vdc (for CCC only)

Dimension
(W x H x L)

• 73.5 x 40 x 203 mm

Input

• 100-127Vac / 9.8 - 7A / 50-60Hz
• 200-240Vac / 7 - 5A / 50-60Hz
• 200-240Vdc / 7 - 5A (for CCC only)

+12V

• Max: 66.7A / Min: 0A (100-127Vac)
• Max: 83A / Min: 0A (200-240Vac)
• Max: 83A / Min: 0A (200-240Vdc)

12Vsb

• Max: 2.1A / Min: 0A

Output Type

• 25 Pairs Gold Finger Connector

Certification Titanium Level
[Test Report]PC Health MonitoringVoltage

• Monitors for CPU Cores, +1.8V, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory Voltages.
• 5+1 Phase-switching voltage regulator

FAN

• 8x 4-pin fan headers
• Status monitor for speed control
• Pulse Width Modulated (PWM) fan connectors

Temperature

• Support to monitor Supermicro AOC temperatures from IPMI or SD 5
• Monitoring for CPU and chassis environment
• CPU thermal trip support
• Thermal Control for 8x Fan Connectors
• Thermal Monitor 2 (TM2) support
• PECI

LED

• Memory DIMM ECC error LEDs
• CPU / System Overheat LED
• Suspend static indicator LED
• UID/Remote UID

Other Features

• 4x 8-pin GPU power connectors
• Chassis intrusion detection
• Chassis intrusion header
• SDDC Support
• RoHS

Operating Environment / ComplianceRoHS

• RoHS Compliant

Environmental Spec.

• Operating Temperature:
  10°C to 35°C (50°F to 95°F)
• Non-operating Temperature:
  -40°C to 70°C (-40°F to 158°F)
• Operating Relative Humidity:
  8% to 90% (non-condensing)
• Non-operating Relative Humidity:
  5% to 95% (non-condensing)

Parts ListParts List - (Items Included)
Part Number
Qty
Description
Motherboard / ChassisMBD-X10DRU-i+
CSE-219UE1C4-R1K02-T1
1Super X10DRU-i+ Motherboard
2U ChassisAdd-on Card / ModuleAOC-2URN4-I4XT12U Ultra Riser based on Intel X540 controller with 4 10Gbase-T ports, 4 NVMe ports, and 1 internal PCI-E x8 3.0 slotAir 2U SAS3 12Gbps single-expander backplane, support up to 20x 2.5-inch SAS3/SATA3 HDD/SSD and 4x NVMe/SAS3/SATA3 storage devicesCable 1CBL-SAST-05932MINI SAS HD,12G,INT,60CM,30AWGCable 2CBL-SAST-06584MINI SAS HD,INT,PCIe NVMe SSD, 60CM,30AWGCable 3CBL-PWEX-067338 pin female to 2x big 4 pin female power, 65/70CM, 18AWG,RoHS/REACHDrive Tray(s)MCP-220-00127-0B4Black gen-3 2.5 NVMe drive tray, Orange tab with lock (for hotswap NVMe LABEL FOR REDUNDANT PWR QRG,HF,RoHS/REACHRiser CardRSC-R2UW-4E812U LHS WIO Riser card with four PCI-E x4 slotsRiser CardRSC-R1UW-E8R11U RHS WIO Riser card with one PCI-E x8 slotHeatsink / RetentionSNK-P0058PSU22U Passive CPU Heat Sink for X10 2U 24-DIMM Ultra Series Servers,RoHS/REACHPower SupplyPWS-1K02A-1R21U 1000W Redundant Power Supply 73.5mm width Titanium Level,RoHS/REACHMounting RailsMCP-290-00053-0N
MCP-290-00060-0N1
1Inner/outer rail set, quick-release type, 26.5" to 36.4"
Threaded rail adapter default for round hole rack
