Features:

• Support 4G+ Cat6*:Insert a Nano SIM card to enjoy up to 300 Mbps (Not compatible with AT&T's Text & Data plans**in the US).
• AX3000 Dual-Band WiFi 6: Supports2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz
• 6 Gigabit Ethernet Ports: Provide high-speed wired connectivity.
• 5 High-Gain Detachable Antennas:Extend and concentrate the Wi-Fi signals.
• Centralized Management: Cloud access and the Omada app for easy management.
• Omada Mesh:Seamlessly connects to EAPs that support mesh technology.

• 4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32 (2100/1800/850/2600/900/800/700/1450 MHz)
• 4G LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz)
• 3G DC-HSDPA/HSPA+/HSDPA/HSUPA/WCDMA: B1/B3/B5/B8 (2100/1800/850/900 MHz)

Carrier Aggregation of EU:
B3+B3/B5/B7/B8/B20/B28/B38/B40/B41
B5+B5/B7/B38/B40/B41
B7+B7/B8/B20/B28/B32
B8+B32/B38/B40/B41
B20+B32/B38/B40
B28+B32/B38/B40/B41
B38+B38
B40+B40
B41+B41

LTE Band of US:
• 4G LTE-FDD: MHz)
• 4G LTE-TDD: B41/B48 (2500/3600 MHz)

Carrier Aggregation of US:
B4+B4/B5/B7/B12/B13/B29/B30/B71
B5+B5/B7/B25/B30/B41/B66
B7+B7/B12/B66
B12+B12/B25/B30/B66
B13+B66
B14+B30/B66
B25+B25/B26/B41
B26+B41
B29+B30/B66
B30+B66
B41+B41
B48+B48
B66+B66/B71

• Uplink: 50 Mbps

• URL Filtering
• Web Security†

• ARP Scanning†
• IP-MAC Binding

• Block TCP Scan (Stealth FIN/Xmas/Null)
• Block Ping from WAN

• 1 Gigabit WAN Port
• 4 Gigabit LAN/WAN Ports

• 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
• 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)

• 5 GHz: 2402 Mbps (HE160)

• LTE: Two 4.0dBi omnidirectional detachable antennas

US: 17.3W

• Mesh (with EAP that supports Mesh)
• OFDMA
• Beamforming
• MU-MIMO
• Rate Limit: Based on SSID/Client
• Airtime Fairness
• Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise
• Multiple SSIDs: 16 in total (8 per radio)

• Encrypted: 282.6Mbps

• ESP-SHA256-AES256: 654.4Mbps
• ESP-SHA384-AES256: 646.5Mbps
• ESP-SHA512-AES256: 670.5 Mbps

• Encrypted: 475.0Mbps

• Encrypted: 177.4Mbps

• Dynamic IP
• PPPoE (supports MRU Configuration)
• PPTP
• L2TP

• DHCPv6 PD Server (only in Standalone Mode)
• DHCP Options Customization
• DHCP Address Reservation
• Multi-IP Interfaces
• Multi-Net DHCP

• Policy Routing
• RIP†
• OSPF†

• Application Optimized Routing
• Link Backup (Timing, Failover)
• Online Detection

• Multi-Net NAT
• Port Forwarding
• Port Triggering†
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG
• UPnP

• LAN-to-LAN, Client-to-LAN
• Main, Aggressive Negotiation Mode
• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
• IPsec Failover
• IKE v1/v2
• MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
• NAT Traversal (NAT-T)
• Dead Peer Detection (DPD)
• Perfect Forward Secrecy (PFS)

• PPTP VPN Client (10)
• 50 Tunnels
• PPTP with MPPE Encryption

• L2TP VPN Client (10)
• 50 Tunnels
• L2TP over IPSec

• OpenVPN Client (5)
• 55 OpenVPN Tunnels
• "Certificate + Account" Mode
• Full Mode

• Simple Password§
• Hotspot (Local User / Voucher§/ SMS§/ Radius§)
• External Radius Sever
• External Portal Sever§
• LDAP

• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller

Customization)

• Remote Management
• Export & Import Configuration
• SNMP v1/v2c/v3
• Diagnostics (Ping & Traceroute)
• NTP Synchronize†
• Port Mirroring
• CLI (only in Standalone Mode)
• Syslog Support

• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• Captive Portal Configuration

• Power Adapter
• Quick Installation Guide

• MAC OS, NetWare, UNIX or Linux

Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
