Transition Networks RJ-45 to SX SMF Media Converter M/GE-PSW-LX-01-NA
NEW - OPEN BOX.
Features

• Unit & Port LEDs allow for quick statusinformation
• Auto-Negotiation
• Fixed Full-Duplex on fiber
• Auto-MDI/MDIX
• Active Link Pass Through
• Automatic Link Restoration
• Space saving design
• Connect Legacy NetworkingEquipment: Connect an existing 10/100Mbps device to 1000 Mbps devices.
• Jumbo Frame (up to 10,240 Bytes)
• USB Power Option, requires the use of a USB to DC barrel connector cable (USBC-AM-DC)

Standards

• IEEE 802.3

Data Rate

• 10/100/1000 Mbps

Max Frame Size

• Up to 10,240 bytes

Status LEDs

• PWR (Power): (below RJ-45) ON = Lit for normal operation
• FX-Link/Act (Fiber Link/Activity): (Upper Left on RJ-45) ON = Link; Flashing = Activity
• TX-Link/Act (Copper Link/Activity): (Upper Right on RJ-45) ON = Link; Flashing = Activity

Dimensions

• Width: 1.8” [46 mm]
• Depth: 3.3” [85 mm]
• Height: 0.85” [22 mm]

Power Consumption

• 3.15 Watts

Power Supply

• Unit accepts 4.5 VDC to 28 VDC
• Wall Mount AC adapter: 12 VDC 400mA

Environment

• Operating: 0°C to 50°C
• Storage: -15°C to +65°C
• Humidity: 5% to 95% (non-condensing)
• Altitude: 0 – 10,000 ft.

Weight

• 2 lbs. [0.90 kg]

MTBF

• 24,466 hours (MIL217F2 V5.0) (MIL-HDBD-217F)
• 100,130 hours (Bellcore7 V5.0)

Certifications

• Safety: Wall Mount Power Supply, UL Listed, cUL Listed (Canada) FCC Class A, CISPR22/EN55022 Class A, EN55024, CE Mark

Warranty

• Lifetime
