Item DescriptionSMART3000NET intelligent line-interactive large tower UPS system protects servers, networking accessories and telecommunications equipment from blackouts, voltage fluctuations and transient surges. Large internal batteries offer 23 minutes half-load runtime and 7 minutes fully loaded. Runtime is expandable with optional BP24V28-2U (limit 1) and BP24V70-3U (multi-pack compatible) external battery packs. 3000VA/2400W power handling capability supports a variety of networking, telecom and other sensitive electronic applications. Includes eight protected outlets. Supports remote monitoring of UPS and site power conditions via built-in RS-232 enabled monitoring port, plus standard UPS monitoring via two built-in contact closure ports. PowerAlert UPS monitoring software is available for free download. Built-in audible alarm and front-panel LEDs indicate line power, battery power, battery charge level, load level and voltage regulation status. Network-grade AC surge suppression protects equipment from damage and performance problems resulting from transient surges.LEDS ALARMS & SWITCHES

LED Indicators: (5) LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status
Alarms Audible alarm indicates power-failure and low-battery conditions
Alarm cancel operation: Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate low-battery status
Switches: (2) Switches control off/on power status and alarm-cancel/self-test operation; set of 4 rear-panel switches control system enable and contact closure port inverter shutoff commands

SURGE / NOISE SUPPRESSION

UPS AC suppression joule rating: 480
UPS AC suppression response time: Instantaneous
EMI / RFI AC noise suppression: Yes

PHYSICAL

Installation form factors supported with included accessories: Tower
Primary form factor: Tower
OUTPUT

Output Capacity: 3000VA/2400W
Output power factor: 0.8
Output Capacity Details: Output capacity de-rates to 1600 watts with one battery pack and 1250 watts with 2 or more external battery packs connected
Nominal Output Voltages Supported: 120V
Frequency compatibility: 60Hz
Output voltage regulation (line mode): -13% / +5%
Output voltage regulation (battery mode): +/- 5%
Output circuit breaker: 15A branch rated (x2) - each breaker protects (4) outlets
Output AC waveform (AC mode): Sine wave
Output AC waveform (battery mode): PWM sine wave

INPUT

Rated input current (at maximum load): 22A
Nominal Input Voltages Supported: 120VAC
Recommended Electrical Service: 30A, 120V

BATTERY

Full load runtime: 7 min. (2400W)
Half load runtime: 23 min. (1200W)
Expandable battery runtime: Extended runtime supported via OPTIONAL external battery packs; output capacity de-ratings apply
External battery pack compatibility: BP24V28-2U (limit 1); BP24V70-3U (multi-pack compatible)
DC system voltage: 24VDC
Battery recharge rate (included batteries): Less than 9 hours from 10% to 90%

VOLTAGE REGULATION

Voltage regulation description: Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 87 to 140V
Overvoltage correction: Input voltages between 127 and 140V are reduced by 12%
Undervoltage correction: Input voltages between 95 and 105V are boosted by 10%
Severe undervoltage correction: Input voltages between 87 and 94V are boosted by 22%# Ports: 8Communication Interface: Serial (RS-232)Connector: Power NEMA L5-30Connector: Power NEMA L5-30P
