New, sealed box.

Protects network data lines from blown NIC cards, garbledtransmissions, lock-ups and hardware failures caused by surges, line noise, ESDand faulty wiring.

• Network Ethernet line surge suppression for 100Base-T, 10Base-T, Token Ring, AS400/Sys3x and RS422 applications
• Ideal protection for NICs, terminals, hubs, printers, LAN equipment, and other internetworking devices
• Protects against the effects of electrostatic discharge
• Reduces blown NIC cards, garbled network transmissions, system lock-ups and hard equipment failure
• 750A circuit breaker; 7.5V nominal clamping voltage
• RJ45 input and output connections with included patch cable

Overview

The DNET1 provides network Ethernet line surge suppressionfor 100Base-T, 10Base-T, Token Ring, AS400/Sys3x and RS422 applications. Surgesuppression is handled with balanced arrays of high-speed avalanche diodes thatdivert excess energies created by electrostatic discharges away from networkinterface connections. This network surge suppressor reduces blown NIC cards,garbled network transmissions, system lock-ups and hard equipment failure bysafely shunting data line surges to ground. Convenient RJ45 input and outputconnections with an included five-inch Ethernet cable enables ideal protectionfor network workstations, printers and other internetworking devices with anetwork connection.

Features

• DNET1 protects network workstations, printers and internetworking devices from surges present on 10/100Base-T, token ring, AS400/Sys3x or RS422 network lines
• Convenient RJ45 input and output connections make for simple installation (RJ45 input/output connections, pins 1-8, 7.5V clamping)
• 5 inch Ethernet patch cable enables ideal protection placed as close as possible to the point of use
• Surge suppression utilizing high speed avalanche diodes divert excess energies on the network to ground
• RoHS Compliance

Package Includes

• DNET1 data line protector

5-in. RJ45 patch cable
