Designed with four display connectivity options, including 1 HDMI, 2 DisplayPort, and 1 VGA port, it effortlessly connects
a variety of displays to meet your needs. ❤NOTE: When you use this dock to connect a Windows-based laptop with
four monitors, the screen of the host computer needs to be turned off.✅ Suitable for UHD Video Enthusiasts - Take your visual experience to the next level with our USB C dock. Equipped with
dual DP ports and an HDMI port, it supports max single 8K@60Hz, dual 4K@60Hz+4K@144Hz or triple 4K@60Hz video
output under DP1.4&DSC1.2. Ideal for video editors, image designers, 8K game players, etc. ❤NOTE: Some Windows laptops
only support 3 monitors(including the host screen) due to their graphic card limitations.
✅ Supports Multiple Display Modes - Enjoy mirror mode for seamless video streaming and presentation demonstrations.
Switch to extend mode for multitasking across multiple windows, perfect for picture designing and stock business. Plus,
experience rotation mode and clamshell mode for even more flexibility. ❤NOTE: All extended displays are the same
on Mac due to its system limitations.
✅ Broad Compatibility & Plug and Play - Designed to be compatible with various USB C devices, our docking station works with
Windows 11/10/8.1/8/7, Mac OS 10.8 or later, Chrome OS, Linux, iPad OS, Harmony OS, iOS, and Android. No drivers required—
simply plug in and transform your device into a multi-function workstation instantly! ❤NOTE: Please make sure the type-c port of
your host device supports video output, or the adapter could not work.
✅ Efficient USB2.0 Connections - Experience lightning-fast connectivity with our USB C laptop docking station. Featuring
three USB-A 2.0 ports, you can effortlessly connect keyboards, mice, U disks, hard disks, printers, etc. With data transfer
speeds of up to 480Mbps, transferring files is a breeze, allowing you to connect these USB peripherals without any lag.
Say goodbye to productivity bottlenecks and embrace efficient workflows.
How to Confirm if the Type-C Port of Your Laptop Supports Video Output?
Step 1: Please check the model of your laptop, it should be on the back of the label;
Step 2: Search “brand + the model number of the device + manual” in Google, for example: “asus ux435 manual”;
Step 3: Check the manual and navigate to the view and check the type-c specification, if it states the type-c port supports display
which means it could support video output. If the specification states bandwidth the type-c port supports only, which means the
type-c port might not support video output. You could also contact the manufacturer to confirm that.
Specification:
1.Model: WL-UMD307
2.Ports: 1x HDMI (4K@60Hz), 1x DP1 (8K@60Hz), 1x DP2(8K@60Hz), 1x VGA(1080P@60Hz), 3 x USB2.0-A(480Mbps)
3.Unit Size: 11.0x5.0x1.5cm/4.3x2.0x0.6in
4.Cable Length: 25cm/9.8in
5.Unit Weight: 85g/3.0oz
6.Housing Material: Aluminum
7.Shell Color: Silver
What’s in the Package?
1 x USB-C Quad Display Docking
1 x Quick Start Guide
Multiple Display Resolution (Max. Resolution)
Notice: Please make sure the type-C port of your host supports video output.
For Windows OS(Some laptops only support 3 monitors due to their graphic card limitations)
1)Single Display:
HDMI: 4K@60Hz(DP1.4&DSC1.2); 4K@60Hz(DP1.4); 4K@60Hz(DP1.2)
DP1: 8K@60Hz(DP1.4&DSC1.2); 4K@60Hz(DP1.4); 4K@60Hz(DP1.2)
DP2: 8K@60Hz(DP1.4&DSC1.2); 4K@60Hz(DP1.4); 4K@60Hz(DP1.2)
VGA: 1080P@60Hz(DP1.4&DSC1.2); 1080P@60Hz(DP1.4); 1080P@60Hz(DP1.2)
2)Dual Display:
HDMI+DP1/DP2: 4K@60Hz+4K@144Hz(DP1.4&DSC1.2); 4K@60Hz+4K@60Hz(DP1.4); 4K@30Hz+4K@30Hz(DP1.2)
HDMI+VGA: 4K@60Hz+1080P@60Hz(DP1.4&DSC1.2); 4K@60Hz+1080P@60Hz(DP1.4); 4K@144Hz+1080P@60Hz(DP1.4&DSC1.2); 4K@60Hz+1080P@60Hz(DP1.4); 4K@60Hz+1080P@60Hz(DP1.2)
DP1+DP2: 4K@144Hz+4K@60Hz(DP1.4&DSC1.2); 4K@60Hz+4K@60Hz(DP1.4); 4K@30Hz+4K@30Hz(DP1.2)
3)Triple Display:
HDMI+DP1/DP2+VGA: 4K@60Hz+4K@60Hz+1080P@30Hz(DP1.4); 4K@60Hz+4K@60Hz+1080P@30Hz(DP1.4); 4K@60Hz+4K@60Hz+1080P@30Hz(DP1.4); Display
HDMI+DP1+DP2+VGA: Not Support(DP1.2)
For Mac OS(only supports extend 1 external monitor with different content)
1)Single Display:
HDMI: 4K@60Hz(DP1.4&DP1.2)
DP1: 4K@60Hz(DP1.4&DP1.2)
DP2: 4K@60Hz(DP1.4&DP1.2)
VGA: Display:
HDMI+DP1/DP2: 2x4K@60Hz(DP1.4&DP1.2)
DP1+DP2: 2x4K@60Hz(DP1.4&DP1.2)
HDMI+VGA: Display:
HDMI+DP1+DP2: Display
HDMI1+HDMI2+DP+VGA: Tips:
-The type-C port of your host should support video output to enjoy the full function of this hub.
-When you use this dock to connect a Windows-based laptop with four monitors, the screen of the host computer needs to be turned off.
-Some Windows laptops only support 3 monitors(including the host screen) due to their graphic card limitations.
-Rotation Mode, Clamshell Mode and HDCP are supported.
-Your USB-C phones/tablets should support the OTG function.
HDMI+2DP+VGA+95W PD+3USB2.0
✅ Quad Displays Docking Station - Experience the ultimate productivity boost with our versatile USB C multiport adapter.
Designed with four display connectivity options, including 2 HDMI, 1 DisplayPort, and 1 VGA port, it effortlessly connects
a variety of displays to meet your needs. ❤NOTE: When you use this dock to connect a Windows-based laptop with
four monitors, the screen of the host computer needs to be turned off.
✅ Suitable for 4K Video Enthusiasts - Take your visual experience to the next level with our USB C dock. Equipped with dual
HDMI and DP ports, it supports up to triple 4K video output (4K@30Hz+4K@30Hz+4K@60Hz) under DP1.4 source. Ideal for
video editors, image designers, 4K game players, etc. ❤NOTE: Some Windows laptops only support 3 monitors(including the
host screen) due to their graphic card limitations.
✅ Supports Multiple Display Modes - Enjoy mirror mode for seamless video streaming and presentation demonstrations.
Switch to extend mode for multitasking across multiple windows, perfect for picture designing and stock business.
Plus, experience rotation mode and clamshell mode for even more flexibility. ❤NOTE: All extended displays are the
same on Mac due to its system limitations.
✅ Broad Compatibility & Plug and Play - Designed to be compatible with various USB C devices, our docking station
works with Windows 11/10/8.1/8/7, Mac OS 10.8 or later, Chrome OS, Linux, iPad OS, Harmony OS, and Android.
No drivers required—simply plug in and transform your device into a multi-function workstation instantly! ❤NOTE:
Please make sure the type-c port of your host device supports video output, or the adapter could not work.
✅ Efficient USB2.0 Connections - Experience lightning-fast connectivity with our USB C laptop docking station.
Featuring three USB-A 2.0 ports, you can effortlessly connect keyboards, mice, U disks, hard disks, printers, etc.
With data transfer speeds of up to 480Mbps, transferring files is a breeze, allowing you to connect these USB peripherals
without any lag. Say goodbye to productivity bottlenecks and embrace efficient workflows.
How to Confirm if the Type-C Port of Your Laptop Supports Video Output and Charging?
Step 1: Please check the model of your laptop, it should be on the back of the label;
Step 2: Search “brand + the model number of the device + manual” in Google, for example: “asus ux435 manual”;
Step 3: Check the manual and navigate to the view and check the type-c specification, if it states it supports power delivery which
means it supports charging. If it states the type-c port supports display which means it could support video output. If the specification
states bandwidth the type-c port supports only, which means the type-c port might not support video output and charging.
You could also contact the manufacturer to confirm that.
pecification:
1.Model: WL-UMD304
2.Ports: 1x HDMI1 (4K@30Hz), 1x HDMI2 (4K@60Hz), 1x DisplayPort(4K@60Hz), 1x VGA(1080P@60Hz), 3 x USB2.0-A(480Mbps)
3.Unit Size: 11.0x5.8x1.9cm/4.3x2.3x0.7in
4.Cable Length: 25cm/9.8in
5.Unit Weight: 85g/3.0oz
6.Housing Material: Aluminum
7.Shell Color: Blue
What’s in the Package?
1 x USB-C Triple Display MST Docking Station
1 x Quick start guide
Multiple Display Resolution (Max. Resolution)
Notice: Please make sure the type-C port of your host supports video output.
For Windows OS(Some laptops only support 3 monitors due to their graphic card limitations)
1)Single Display:
HDMI1: 4K@30Hz(DP1.4); 4K@30Hz(DP1.2)
HDMI2: 4K@60Hz(DP1.4); 4K@60Hz(DP1.2)
DP: 4K@60Hz(DP1.4); 4K@60Hz(DP1.2)
VGA: 1080P@60Hz(DP1.4); 1080P@60Hz(DP1.2)
2)Dual Display:
HDMI1+DP/HDMI2: 4K@30Hz+4K@60Hz(DP1.4); 4K@30Hz+4K@30Hz(DP1.2)
HDMI2+DP: 4K@60Hz+4K@60Hz(DP1.4); 4K@30Hz+4K@60Hz(DP1.2)
HDMI1+VGA: 4K@30Hz+1080P@60Hz(DP1.4); 1080P@60Hz+4K@60Hz(DP1.4); Display:
HDMI1+HDMI2+DP: 4K@30Hz+4K@60Hz+4K@30Hz or 4K@30Hz+4K@30Hz+4K@60Hz or 1080P@30Hz+4K@60Hz+4K@60Hz(DP1.4); 3x1080P@60Hz(DP1.2)
HDMI1+HDMI2+VGA: 4K@30Hz+4K@60Hz+1080P@60Hz(DP1.4); 3x1080P@60Hz(DP1.2)
HDMI2+DP+VGA: 4K@60Hz+4K@60Hz+1080P@60Hz(DP1.4); 3x1080P@60Hz(DP1.2)
HDMI1+DP+VGA: 4K@30Hz+4K@60Hz+1080P@60Hz(DP1.4); 3x1080P@60Hz(DP1.2)
4)Quad Display
HDMI1+HDMI2+DP+VGA: 4x1080P@60Hz(DP1.4); Not Supported(DP1.2)
For Mac OS(only supports extend 1 external monitor with different content)
1)Single Display:
HDMI1: 4K@30Hz(DP1.4&DP1.2)
HDMI2: 4K@60Hz(DP1.4&DP1.2)
DP: 4K@60Hz(DP1.4&DP1.2)
VGA: Display:
HDMI1+DP/HDMI2: Display:
HDMI1+HDMI2+DP: Display
HDMI1+HDMI2+DP+VGA: Tips:
-The type-C port of your host should support video output to enjoy the full function of this hub.
-When you use this dock to connect a Windows-based laptop with four monitors, the screen of the host computer needs to be turned off.
-Some Windows laptops only support 3 monitors(including the host screen) due to their graphic card limitations.
-Rotation Mode, Clamshell Mode and HDCP are supported.
-Your USB-C phones/tablets should support the OTG function.
4HDMI+85W PD
WAVLINK UG7501H Quad 4K@60Hz Universal Display Adapter with 85W Upstream Charging
Empower your workspace with a dynamic USB-C/A display adapter. Featuring four HDMI ports for stunning 4K visuals at 60Hz,
fueled by the cutting-edge DisplayLink DL7400 chipset. Seamless performance for work and entertainment tasks like document managing
and video conferencing. Customize your display effortlessly with mirror and extend modes. Setup is a breeze—download the driver
from the DisplayLink website. Compatible with Windows 11/10, Mac OS 11.x-13.x or later, Chrome OS, Ubuntu, Android and
Harmony OS and most desktops with USB-C and USB-A ports. Choose the WAVLINK WL-UG7501H to
elevate your productivity and visual experience!
85W Fast Upstream Charging
Experience swift and efficient host device charging at 85W using the powerful 100W USB-C charging port,
which is designed specifically for charging, not for data transfer or video output.
High-Performance Chipset
The DisplayLink DL7400 chipset delivers fast data transfer speeds and reliable visual transmissions,
ideal for both work tasks and everyday use.
Rotation & Clamshell Mode
Rotation Mode allows users to switch their computer screen from landscape to portrait orientation,
while Clamshell Mode could transform the laptop into a desktop-like setup for tasks requiring more screen space or display options.
Note: Rotation & Clamshell Mode are available on Windows and Mac OS 12.x above.
Premiun Shell Design
The aluminum alloy casing serves to provide enhanced durability, heat dissipation, and a premium aesthetic appearance,
ensuring both protection and efficient performance.
Compatible Systems
-Windows 11/10
-Mac OS 11.x-13.x or later
-Chrome OS
-Ubuntu
-Android
-Harmony OS
Multiple Display Resolution(Max. Resolution)
1) Single Display:
HDMI1/HDMI2/HDMI3/HDMI4: 4K(3840x2160)@60Hz.
2) Dual Display:
HDMI1+ HDMI2: 2*4K(3840x2160)@60Hz;
HDMI1/2+ HDMI3/4: 2*4K(3840x2160)@60Hz;
HDMI3+ HDMI4: 2*4K(3840x2160)@60Hz.
3) Triple Display:
HDMI1+HDMI2+HDMI3/4: 3*4K(3840x2160)@60Hz.
4) Quadruple Display:
HDMI 1+HDMI 2+HDMI3+HDMI4: WL-UG7501H
2.Chip: DisplayLink DL7400
3.Connection to Host: USB-C/A
4.Video Ports: 4 x HDMI
5.Product Size: 11.3 x 9.9 x 1.5cm/4.5x3.9x0.6in (L x W x H)
6.Cable Length: 23cm/9.1in
7.Product Weight: 206g/7.3oz
Features
- 4 x HDMI ports support quad 4K@60Hz.
- 1 x USB-C/A 2-in-1 cable, easily connect to the host.
- 1 x USB-C 100W PD in charging to the laptop.
Warm Tips
☺Not plug-and-play supported; please download and install drivers from the official website.
☺Ideal for light office use; not recommended for graphic-intensive tasks like gaming or video editing.
☺Please confirm that the type-c port of your laptop supports charging, or the adapter's host charging function may not work.
☺The charger and charging cable are not included.
☺The USB-C port on the adapter is only for charging, does not support data transfer or video output.
☺Not for other Linux, iOS or iPad OS systems. Does not support Steam Deck or Nintendo Switch.
☺Does not support HDCP, will not playback encrypted or copy-protected content from Netflix, Hulu, iTunes, Amazon Prime, etc.
In the Box
- 1 x Quad 4K@60Hz Universal Display Adapter
- 1 x Quick Start Guide
2HDMI+2DP+85W PD
WAVLINK UG7501DH Quad 4K/Dual DP 8K Universal Display Adapter with 85W Upstream Charging
Empower your workspace with a dynamic USB-C/A display adapter. Featuring DP/HDMI ports for stunning 8K/4K visuals,
fueled by the cutting-edge DisplayLink DL7400 chipset. Seamless performance for work and entertainment tasks like document
managing and video conferencing. Customize your display effortlessly with mirror and extend modes. Setup is a breeze—download
the driver from the DisplayLink website. Compatible with Windows 11/10, Mac OS 11.x-13.x or later, Chrome OS, Ubuntu,
Android and Harmony OS and most desktops with USB-C and USB-A ports. Choose the WAVLINK WL-UG7501DH to
elevate your productivity and visual experience!
85W Fast Upstream Charging
Experience swift and efficient host device charging at 85W using the powerful 100W USB-C charging port,
which is designed specifically for charging, not for data transfer or video output.
High-Performance Chipset
The DisplayLink DL7400 chipset delivers fast data transfer speeds and reliable visual transmissions, ideal for both work tasks and everyday use.
Rotation & Clamshell Mode
Rotation Mode allows users to switch their computer screen from landscape to portrait orientation, while Clamshell Mode could transform
the laptop into a desktop-like setup for tasks requiring more screen space or display options. Note: Rotation & Clamshell Mode are available
on Windows and Mac OS 12.x above.
Premiun Shell Design
The aluminum alloy casing serves to provide enhanced durability, heat dissipation, and a premium aesthetic appearance,
ensuring both protection and efficient performance.
Compatible Systems
-Windows 11/10
-Mac OS 11.x-13.x or later
-Chrome OS
-Ubuntu
-Android
-Harmony OS
Multiple Display Resolution(Max. Resolution)
1) Single Display:
DP 1 (DSC): 8K@60Hz/4K@144Hz
DP 2: 8K@60Hz/4K@120Hz
HDMI 1/2: 4K@60Hz
2) Dual Display:
DP 1 (DSC)+DP 2: 8K@60Hz/4K@144Hz+8K@60Hz/4K@120Hz
DP 1 (DSC)+HDMI 1/2: 8K@60Hz/4K@144Hz+4K@60Hz
DP 2+HDMI 1/2: 8K@60Hz/4K@120Hz+4K@60Hz
HDMI 1+HDMI 2: 2*4K@60Hz
3) Triple Display:
DP 1 (DSC)+DP 2+HDMI 1/2: 8K@60Hz/4K@144Hz+4K@120Hz+4K@60Hz or 4K@144Hz+8K@60Hz+4K@60Hz
DP 1 (DSC)+HDMI 1+HDMI 2: 8K@60Hz/4K@144Hz+2*4K@60Hz
DP 2 +HDMI 1+HDMI 2: 8K@60Hz/4K@120Hz+2*4K@60Hz
4) Quadruple Display:
DP 1 (DSC)+DP2+HDMI 1+HDMI 2: WL-UG7501DH
2.Chip: DisplayLink DL7400
3.Connection to Host: USB-C/A
4.Video Ports: 2 x HDMI, 2 x DP
5.Product Size: 11.3 x 9.9 x 1.5cm/4.5x3.9x0.6in (L x W x H)
6.Cable Length: 23cm/9.1in
7.Product Weight: 206g/7.3oz
Features
- 2 x DP & 2 x HDMI ports support dual 8K@60Hz and quad 4K@60Hz.
- 1 x USB-C/A 2-in-1 cable, easily connect to the host.
- 1 x USB-C 100W PD in charging to the laptop.
Warm Tips
☺Not plug-and-play supported; please download and install drivers from the official website.
☺Ideal for light office use; not recommended for graphic-intensive tasks like gaming or video editing.
☺Please confirm that the type-c port of your laptop supports charging, or the adapter's host charging function may not work.
☺The charger and charging cable are not included.
☺The USB-C port on the adapter is only for charging, does not support data transfer or video output.
☺Not for other Linux, iOS or iPad OS systems. Does not support Steam Deck or Nintendo Switch.
☺Does not support HDCP, will not playback encrypted or copy-protected content from Netflix, Hulu, iTunes, Amazon Prime, etc.
In the Box
- 1 x Quad 4K/Dual 8K DisplayPorts Universal Display Adapter
- 1 x Quick Start Guide
