Technical Specifications
Mechanical DimensionsWithout radome: 520 x 520 x 308 mm (20.5 x 20.5 x 12.1")
With radome: 525 x 525 x 315 mm (20.7 x 20.7 x 12.4" WeightWithout radome: 2.35 kg (5.18 lb)
With radome: 3.2 kg (7 lb) Enclosure materialUV-stabilized plastic MountingPole mount kit (Included) Wind loading264.6 N at 96 km/h (60 lbf at 60 mph) Wind survivability96 km/h (60 mph) Hardware Networking interface (1) GbE RJ45 port Power method Passive PoE (Pairs 4, 5+; 7, 8 Return) Power supply24V, 0.5A Gigabit PoE Max. power consumption 8.5W Supported voltage range 20-26V DC ESD/EMP protectionAir/contact: ± 24 kV LEDs(1) Power, (1) LAN, (4) WLAN Signal strength LEDsSoftware-adjustable to correspond to custom RSSI levels RoHS compliance Yes Salt fog testIEC 68-2-11 (ASTM B117)
Equivalent: MIL-STD-810 G method 509.5 Vibration testIEC 68-2-6 Temperature shock testIEC 68-2-14 UV testIEC 68-2-5 at 40° C (104° F)
Equivalent: ETS 300 019-1-4 Wind-driven rain test ETS 300 019-1-4
Equivalent: MIL-STD-810 G method 506.5 Operating temperature-40 to 70° C (-40 to 158° F) Operating humidity5 to 95% noncondensing Certifications FCC, IC, CE System Gain27 dBi Max. VSWR 1.5:1 Channel sizes
PtP Mode
PtMP Mode
10/20/30/40/50/60/80 MHz
10/20/30/40 MHz PolarizationDual linear Operating Frequency (MHz) Worldwide 5150 - 5875 MHz – 5250 MHz
5250 – 5350 MHz
5470 – 5725 MHz
5725 – 5850 MHz
