Switch Enterprise Campus 48S Model: ECS-48S Product Description

Technical Specifications Switching Capacity680 GbpsTotal Non-Blocking Throughput340 GbpsForwarding Rate506 Mpps1 GbE RJ451(1G/100M/10M)2.5 GbE RJ4532(2.5G/1G/100M/10M)10 GbE RJ4516(10G/5G/2.5G/1G/100M/10M)25G SFP284(25G/10G/1G)Console1Layer 3YesPower Supply(2) Hot-swappable AC/DC 550W power modulesPower Method(2) Universal input, 100–240V AC, 50/60 HzMax. Power Consumption250WSupported VLANs1,000MAC Address Table Size32,000Form FactorRack Mount (1U, Full-Depth)Dimensions442.4 x 44 x 496 mm(17.4 x 1.7 x 19.5")WeightWithout mounting brackets: 10.2 kg (22.5 lb)With mounting brackets: 10.3 kg (22.7 lb)NDAA CompliantYesCertificationsCE, FCC, ICAmbient Operating Temperature-5 to 40° C (23 to 104° F)Ambient Operating Humidity10 to 90% noncondensing100G QSFP282(100G)802.1X ControlYesESD ProtectionAir: ± 12kV, contact: ± 8kVEnclosure MaterialSGCC steelEtherlighting™YesFan Method(4) Hot-swappable fan modulesFlow ControlYesHeat Dissipation853 BTU/hrIGMP SnoopingYesIPv4256Jumbo FramesYesLACP Port AggregationYesLCM Display1.3" touchscreenLoop Management portSerial ConsoleARMount MaterialSGCC steelPacket Buffer Size8 MBPort MirroringYesPower Input Method(2) AC input, Hot-swappable power modulesQoS (DSCP)YesRedundancySwitch Stacking(2) Hot-Swappable PSUs(4) Hot-Swappable FansSTP & RSTPYesStorm ControlYesSupported Rack Depth482.6 mm (19") four-post racksPosts depths ranging from 650 to 1,000 mm (25.6–39.4”)Supported Voltage Range100–240V ACUniFi NetworkVersion 10.6.101 and later 📦 Brand New - Factory Sealed 🛡️ Manufacturer Warranty 🚚 Fast Free Shipping with Tracking
