Professional Ubiquiti UniFi Pro Aggregation Layer 3 Fiber Switch
UPC: 810010072597
MPN: USW-Pro-Aggregation
Brand: Ubiquiti
Type: Aggregation Switch
Model: USW-Pro-Aggregation
Number of LAN Ports: 32
Ethernet Technology: 25 Gigabit Ethernet (25GbE)
Network Management Type: Fully Managed
Form Factor: Rack Mountable
Maximum LAN Data Rate: 25 Gbps
Product Line: UniFi
Alternative Models & Cross-Brand Equivalents
For buyers cross-referencing specific PC builds or motherboard QVL lists, this item shares identical core specifications with, or is a direct physical variant of, the following manufacturer part numbers:
- USW-Aggregation
- USW-Pro-XG-Aggregation
- ECS-Aggregation
- US-16-XG
- MikroTik CRS326-24S+2Q+RM
- FS.com S5860-20SQ
- TP-Link TL-SX3016F
- QNAP QSW-M5216-1T
Port Configuration & PoE Capabilities
The USW-Pro-Aggregation is a high-density fiber solution featuring 28 1/10 Gbps SFP+ ports and 4 1/10/25 Gbps SFP28 ports. This configuration provides massive bandwidth for enterprise-grade downlinks and high-speed core uplinks. Please note that this is a dedicated fiber aggregation switch and does not provide PoE output.
- High-Speed Uplinks: Four SFP28 ports support up to 25Gbps for core network connectivity.
- SFP28 Speed Logic: To maintain signal integrity, if one SFP28 port is set to 25Gbps, all four must operate at 25Gbps.
Management, OS & Layer Features
This is a fully managed Layer 3 switch integrated into the UniFi ecosystem. It supports advanced features including inter-VLAN routing, static routing, and DHCP server capabilities. The front-facing 1.3" LCM color touchscreen provides instant status updates and supports Augmented Reality (AR) switch management via the UniFi mobile app for rapid port identification.
- Layer 3 Performance: High-capacity 760 Gbps switching capacity with a 565.44 Mpps forwarding rate.
- UniFi Integration: Managed via the UniFi Network Controller for centralized configuration and monitoring.
- Enterprise Security: Includes ACL support and robust network isolation features.
Hardware Configuration & Included Accessories
Built for reliability in demanding environments, the unit features a 1U rack-mountable SGCC steel enclosure. It includes a primary universal AC input and a USP-RPS DC input for mission-critical power redundancy. The cooling system is designed for silent but effective thermal management in standard server racks.
- Power Redundancy: Compatible with the UniFi SmartPower RPS for seamless failover protection.
- Build Quality: Professional-grade steel construction with a maximum power consumption of 100W.
- Visual Management: The LCM touchscreen allows for quick troubleshooting without needing console access.
