✅ Offline Clone Function - Wavlink hard drive docking station supports offline clone function, it can be used to clone an
existing hard drive without connecting to a computer, easy to duplicate data from one to another hard drive by pressing
the CLONE button for about 3 seconds. Please note the target disk must be larger than the source disk.

✅ Dual Bay Connections - This dock offers an easy access with two 2.5/3.5 inches HDD SSD SATA I/II/III drives,
which is a perfect solution for backup & processing IT data, batch processing data, data recovery, formatting and file transferring.
The dust-proof design of the cover gives you a unique experience.

✅ Extensive Capacity - This dock enables access to 2 drives simultaneously(Up to 2×16TB). LED indicator light shows power
and activity status. Support plug and play & hot swap. On/Off power switch for hard drives protection. Compatible with Windows,
Mac OS, Linux and Android. {Note: Your phone should support OTG function then you can easily read the hard disk data.}

✅ UASP Accelerated - Super speed USB 3.0 data file transfers (up to 5 Gbps/420MB/s) from your computer to back-up files
and centralize storage for convenient access. Up to 70% faster at read speed and 40% faster at write speed over traditional USB 3.0,
downward compatible with USB 2.0/1.1.

✅ We Care For You - This adapter features a light weight, perfect for the occasion of home office, watching movies, entertainment etc.
What you will get: 1 x USB 3.0 Dual Bay Docking Station, 1 x USB-B to USB-A Cable, 1x Power Adapter 12V/3A, 1 x USB-A to USB-C Adapter,
1 x Quick Start Guide. 1-Year worry-free warranty (extra 6 months for registered members) and life-long friendly customer service and technical support.

Instructions on How to Connect the Dock to the Computer:
1). Please unplug the DC power adapter to make sure that the power is off before starting.
2). Insert HDDs/SSDs into the slots vertically and slowly until them stick.(One HDD/SSD is also supported)
3). Connect the power adapter and turn the "ON-OFF" switch on.
4). Connect the USB cable to the computer then you can use it as your computer's external hard drive.

How to Operate Offline Clone Function:
ѧ Please unplug the DC power adapter to make sure that the power is off before starting.
ѧ Insert Source Disk into hard drive bay A, then insert Target Disk into hard drive bay B.
ѧ Make sure the USB cable is disconnected from computer.
ѧ Connect the power adapter and turn the"ON-OFF" switch on.
ѧ Hold the CLONE button for about 3 seconds, when all leds turn on, the clone progress will start.
ѧ Four lights (25%, 50%, 75%, 100% ) will turn solid blue when the cloning process is completed.
ѧ Finally turn the "ON-OFF" switch off, disconnect the power adapter and eject your drives.

Tips for Offline Clone:
- The capacity of target disk must be larger than the source disk.
- Please confirm that your source drive and target drive can both work properly.
- Please connect the 12V power adapter to ensure a stable power supply for transmission.
- To avoid data transfer errors, overheating and damage to the device, please make sure that there are no faulty driver cells.
- To avoid data loss, do not remove or insert drives when one drive is working in the docking station.
Please power off the dock before removing.
- Please confirm the target drive have no data. If you have existing data on the target drive, the cloning process will
eliminate your target drive's data. Because the target drive will be cloned to be the same as the source drive, partition, format
and data are the same too.

✅ Transfer Data at Blazing 10Gbps - Experience unparalleled speed with RapidFire S2 as it supports lightning-fast data
transfers through its USB-C 3.2 Gen 2 port, delivering speeds of up to 10Gbps. The included USB-C to A adapter ensures
a wider application. Before using the USB-A adapter, connect it to the dock to check which side supports 10Gbps data transfer.

✅ Effortless One-Click Cloning - Simplify your data management with the convenient one-click cloning function.
Please note that the source disk capacity should not exceed the target disk capacity. Cloning is unavailable when the dock is
connected to the host, so ensure the power connection, but DO NOT connect the host while cloning.

✅ Works with M.2 PCIe SSDs - RapidFire S2 supports a diverse range of SSDs, supporting M Key/B+M Key NVMe SSDs in
sizes ranging from 22110 to 2230, allowing you to enjoy exceptional storage expansion capabilities of up to 2x8TB.
The source slot is also compatible with AHCI SSDs, though it requires an AHCI to M.2 adapter (not included).

✅ Universal Compatibility - Compatible with Windows, Mac OS, Chrome OS, Linux, Android, iOS, Harmony OS, and iPad OS,
and applicable with USB-C/A hosts, including laptops, tablets, phones (OTG), PS5, projectors, etc., the RapidFire S2 provides you
with excellent versatility. Whether you need to expand storage or clone data, RapidFire S2 ensures reliable performance and
enhances your overall user experience.

✅ Plug & Play Convenience - Simply connect the docking station to your main device and start using it instantly without driver installation,
ensuring a smooth and efficient workflow. With the integrated gravity-balanced design and anti-slip silicone pad, you can install the SSDs
with just one hand, getting rid of complex installation steps.

Specification:
1.Model: WL-Rapid Fire S2
2.LED: 1xPower LED(blue); 2xSSD LED(white); 4xClone LED(blue)
3.Unit Size: Length: 24cm/9.5in
Power Adapter Cable Length: 100cm/39.4in
5.Unit Weight: 98g/3.5oz
6.Housing Material: ABS

In the Box
- 1 x USB-C Dual NVMe M.2 SSD Docking Station
- 1 x Power Adapter
- 1 x USB-A Adapter
- 1 x Quick Start Guide

Warm Tips:
- Only the source slot supports AHCI SSD, and the AHCI to M.2 adapter is required(not included).
- Performance will be limited if the standard of the host USB port is lower than USB 3.2 Gen 2.
- The NVMe/SATA SSD is not included in the package.
- Before using the USB-A adapter, connect it to the dock to check which side supports 10Gbps data transfer.
- If the SSD is brand-new and unformatted, please perform partition installation so that the computer can read the data normally.
If the SSD is formatted and has stored data, you have no need to perform partition installation because the computer can read the data normally.
- Notes for offline cloning:
(1)Capacity requirements: source disk ＜ target disk.
(2)Please connect the power supply but DO NOT connect the host while cloning.
(3)Do not touch the SSD during operation and be cautious of its heated surface.
(4)Cloning duration varies based on the SSD size (not data size).
- Notes for data security:
(1)Before removing the SSD, perform a safe removal operation to prevent data loss and hard disk damage.
(2)Back up all crucial data before the offline cloning.
(3)Avoid forcibly disconnecting the device during data cloning to prevent data loss and hard disk damage.

2-Bay-USB-C to 2.5''/3.5'' SATA HDD/SSD, 44TB, 4 RAID Modes

✅ Ultimate Storage Versatility: Featuring two SATA 6Gbit/s bays, the enclosure supports both 3.5'' and 2.5'' hard drives and SSDs.
Effortlessly expand your storage capacity up to 2x22TB, ensuring you have ample space for all your critical data, multimedia projects,
and extensive game libraries. Note: For 2.5'' hard drives, additional 2.5'' to 3.5'' mounting brackets are required(Not included).

✅ Blazing Fast Data Transfer: Experience unparalleled data transfer speeds with the USB 3.2 Type-C port, capable of reaching up to 10Gbps.
Seamlessly handle massive files and high-volume data transfers with exceptional efficiency and speed, perfect for both professional and personal use.

✅ Enhanced Connectivity & 4 RAID Modes: Beyond storage, this docking station features an additional USB 3.2 Type-C port for
connecting peripherals or daisy-chaining devices, creating a seamless and efficient workspace. The enclosure offers 4 Raid modes to
meet your various needs, whether you want to back up data, transfer files swiftly, read and write on two HDDs simultaneously, or expand storage capacity.

✅ Premium Build Quality and Cooling: Constructed from high-quality aluminum, the docking station offers superior heat dissipation and
robust structural integrity. Dual built-in fans automatically activate at 48°C, ensuring your drives remain cool and perform optimally,
even during intensive tasks.

✅ Hot-Swappable & Computer-Linked Control: Swapping hard disks without shutting down the host, which saves significant time,
lowers the risk of system and data disruption, and enhances the flexibility and convenience of hard disk utilization. Also supports
computer-linked control, offering a simple management solution to increase data security and operational efficiency.

HDD Installation Steps
Step 1: Remove the brackets.
Step 2: Place HDD 1&2 into the brackets and secure them.
Step 3: Reinstall the brackets.
Step 4: Tighten the screws on the bottom.

Compatibility Notes
Systems: Windows, Mac OS, Chrome OS, Linux, Android, iOS, Harmony OS, iPad OS;
Host: Computers/phones/tablets with a USB-C/USB-A port;
HDD/SSD: 3.5" and 2.5'' SATA HDD/SSD. For 2.5'' hard drives, additional 2.5'' to 3.5'' mounting brackets are required(Not WL-RapidFire H2R
2.Unit Size: to C/USB-C to A Cable Length: 80cm/31.5in
Power Adapter Cable Length: 120cm/47.2in
4.Unit Weight: 581g/20.5oz
5.Housing Material: Aluminum Alloy
6.Power LED: Blue
HDD LED: White
RAID LED: Blue

Key Features
- One USB-C upstream port transfers speed up to 10Gbps, and is compatible with USB 3.2/3.1/2.0 computers.
- Dual 3.5" SATA HDD for massive storage capacity expansion.
- RAID 0/1/Large/Normal mode for the data of backup, read and write, and other different needs.
- Supports computer-linked control, with synchronized power on and off for the computer.
- Supports multi-disk daisy-chaining, creating a multi-disk, multi-device, multi-task workstation.
- Thickened aluminum panel, low-noise temperature-controlled fan, and honeycomb ventilation holes for efficient heat dissipation.

In the Box
- 1 x Dual Bay USB-C 3.5"SATA HDD Enclosure
- 1 x Power Adapter
- 2 x Screwdriver
- 1 x USB-C to USB-C Cable
- 1 x USB-C to USB-A Cable
- 1 x Quick Start Guide
- Several Screws

Warm Tips:
- Be sure to make a backup of your data before you set/reset the RAID mode, otherwise your data will be lost.
- The performance will be limited if the host USB-C port standard is lower than USB3.2 Gen2x2.
- For 2.5'' hard drives, additional 2.5'' to 3.5'' mounting brackets are required (Not included).
- Connect up to 3 products via Daisy Chain.
- Supports auto-sleep function, automatically sleeps after 15 minutes of no operation.
- When installing the hard disk, use screws for better stability.
- If the SSD is brand-new and unformatted, please perform partition installation so that the computer can read the data normally.
If the SSD is formatted and has stored data, you have no need to perform partition installation because the computer can read the data normally.

4-Bay-USB-C to 2.5''/3.5'' SATA HDD/SSD, 88TB, 4K HDMI Port

WAVLINK 4-Bay Hard Drive Enclosure for 3.5" and 2.5'' SATA HDD/SSD Featuring 10Gbps USB-C 3.2, 88TB Capacity,
Built-in Temp-Controlled Cooling Fans, HDMI 4K Stunning Video Output, Aluminum Alloy Shell

✅ Ultimate Storage Versatility: Featuring four SATA 6Gbit/s bays, the enclosure supports both 3.5'' and 2.5'' hard drives and SSDs.
Effortlessly expand your storage capacity up to 4x22TB, ensuring you have ample space for all your critical data, multimedia projects,
and extensive game libraries. Note: For 2.5'' hard drives, additional 2.5'' to 3.5'' mounting brackets are required(Not included).

✅ Blazing Fast Data Transfer: Experience unparalleled data transfer speeds with the USB 3.2 Type-C port, capable of reaching up to 10Gbps.
Seamlessly handle massive files and high-volume data transfers with exceptional efficiency and speed, perfect for both professional and personal use.

✅ Enhanced Connectivity and Display Options: Beyond storage, this docking station features an additional USB 3.2 Type-C port for connecting
peripherals or daisy-chaining devices, along with an HDMI interface that supports up to 4K@60Hz resolution(under DP1.4).
Create a seamless and efficient workspace with high-speed connectivity and stunning display capabilities.
Note: Please ensure the USB-C port on your host supports video output and use the USB-C to C cable, or the HDMI port will not work.

✅ Premium Build Quality and Cooling: Constructed from high-quality aluminum, the docking station offers superior heat dissipation and
robust structural integrity. Dual built-in fans automatically activate at 48°C, ensuring your drives remain cool and perform optimally,
even during intensive tasks.

✅ Hot-Swappable Flexibility: Designed for convenience, each of the four bays comes with an independent ON/OFF power switch.
Easily swap drives in and out without powering down the entire system, streamlining your workflow and enhancing productivity.

HDD Installation Steps
Step 1: Remove the brackets.
Step 2: Place HDD 1&2, 3&4 into the brackets.
Step 3: Secure the brackets together.
Step 4: Reinstall the brackets.
Step 5: Tighten the screws on the bottom.

Compatibility Notes
Systems: Windows, Mac OS, Linux, Android, iOS, Harmony OS, iPad OS;
Host: Computers/Phones/Tablets with a USB-C/USB-A port;(Please ensure the USB-C port on your host supports video output and
use the USB-C to C cable, or the HDMI port will not work.)
HDD/SSD: 3.5" and 2.5'' SATA HDD/SSD. For 2.5'' hard drives, additional 2.5'' to 3.5'' mounting brackets are required(Not WL-RapidFire H4
2.Unit Size: to C/USB-C to A Cable Length: 80cm/31.5in
Power Adapter Cable Length(plug end): 120cm/47.2in
Power Adapter Cable Length (round port end): 120cm/47.2in
4.Unit Weight: 1100g/38.8oz
5.Housing Material: Aluminum Alloy
6.Power LED: Blue
HDD LED: White
Power Adapter LED: Green

Key Features
● USB 3.2 Type-C Port: Achieve data transfer rates up to 10Gbps, enabling quick and efficient file transfers and backups.
● Four SATA Bays: Supports up to four 3.5'' or 2.5'' hard drives or SSDs with SATA 6Gbit/s interface, providing vast storage options for your data-intensive tasks.
● Premium Aluminum Construction: Ensures excellent heat dissipation and durability, safeguarding your drives against overheating and physical damage.
● Hot-Swappable Design: With four independent ON/OFF power switches, you can swap drives on-the-fly without powering down the docking station.
● Cooling Fans: Dual fans automatically engage at 48°C, ensuring your drives operate within optimal temperature ranges for enhanced performance and longevity.
● Additional USB 3.2 Type-C Interface: Connect USB peripherals or Daisy-chain additional devices with ease.
● HDMI Output: Supports up to 4K@60Hz resolution for high-quality video output to external displays, enhancing your workstation setup.

In the Box
-1x Quad Bay 3.5" SATA HDD Enclosure
-1 x USB-C to USB-C Cable
-1 x USB-C to USB-A Cable
-1 x Power Adapter
-1 x Power Cable
-1 x Quick Start Guide
-Several Screws

Warm Tips:
- The performance will be limited if the host USB-C port standard is lower than USB3.2 Gen2x2.
- For 2.5'' hard drives, additional 2.5'' to 3.5'' mounting brackets are required (Not included).
- The HDMI port will not work if USB-C port on the host does not support video output or use the USB-C to A cable.
- Connect up to 3 products via Daisy Chain.
- Supports auto-sleep function, automatically sleeps after 15 minutes of no operation.
- When installing the hard disk, use screws for better stability.
- Does not support RAID array setup; configure separately if needed.
- If the SSD is brand-new and unformatted, please perform partition installation so that the computer can read the data normally.
If the SSD is formatted and has stored data, you have no need to perform partition installation because the computer can read the data normally.
