XP Power 650W Single AC-DC Chassis-Mount Power Supply Unit SHP650PS36-EF
Price: US $199.95
Condition: NEW

Warranty:Prime 30 Day Warranty

The SHP350 AC-DC power supply provides up to 420 W of output power in a compact rugged mechanical package, suitable for arange of industrial applications.The unit comprises of a main output with voltages from 12-48 VDC and a 5 VDC standby supply which can be utilitsed with thesignals and control features of the unit to provide detection of loss of AC input and remote on/off Enclosed
  • Dimensions: 9.18 L x 4 W x 2.5 H in
  • Efficiency: 85%
  • Input Voltage Range: 90-264 VAC
  • Isolation Voltage: 3kV (3000V)
  • Mounting Type: Panel Mount
  • Number of Outputs: 2
  • Operation: Switching
  • Output Current: 18A@36V, 0.2A@5V
  • Output Power: 649 W
  • Output Voltage: 5 VDC, 36 VDC
  • Peak Current: 18A
  • Primary Type: AC-DC
  • Series: SHP Series
  • Type: Embedded
