Item description: Brand new 620mm LED Backlight Lamps Update kit Adjustable 15''-27'' LED Light For LCD Monitor Universal Highlight LCD monitor to led backlight Driver board size:7x2cm Input:DC 6-30VOutput: 9.5V6 pin input.
LED strip size:620mm*4mm*3mm (Can be cut by every 3 lamps as a group) The LED Backlight Advantage 1. High brightness up to 700 nits 2. Long operating life, typically lasting over 100,000 hours 3. More energy saving 4. Wide scope of application 5. More environmentally friendly 6. Easy to Install Package: 10x LED backlights 5x Driver board 5x cable Installation: If your monitor is using a inverter, then this kit replace the inveter to plug into the driver board; If your monitor is a high-voltage integrated power supply board, then: the board energized, find 12V (capacitance), and then unplug the power supply,use a multimeter to find and 12V (capacitance) Disconnect original connecting the negative terminal, the board received three line: 12V, ON, GND, the 12v of the inverter connect with 12v positive electrode of hign-voltage intergrated power supply board,GND is connected with the negative electrode, ON connect with the ON / OFF. In simple terms, The original high voltage power supply is disconnected,instead of the inverter, In the original high-pressure front to take power. VIN : voltage ENA: on/off DIM: ADJ adjust brightness GND: connecting Ground
