20X the power, improving the link quality and coverage of certified WLAN devices
Frequency Range:2.4~2.5GHz and 5.725~5.85GHz
Operating Voltage: 6~16V
Receiving Gain: 10dB±1(2.4GHz)/15dB±1(5.8GHz)
Transmission Gain: 13dB±1(2.4GHz)/20dB±1(5.8GHz)
Input Trigger Power:Min: 3dBm Max: 30dBm
Maximum Output Power (P1dB): 36dBm (4W)
EVM: 3%@28dBm 802.11g 54Mbps OFDM 64QAM BW 20MHz
DC Supply Current: 1000mA@Pout 28dBm 9V
Noise Figure: ＜2.5dB(2.4GHz)/＜3.0dB(5.8GHz)
TX/RX Switch Time Delay：＜1us
LED Indicator: Transmitter: Green; Receiver: Red; Transducers: Orange
Operating Ambient Temperature:-40℃～+70℃
Operating Humidity:＜95%RH
Net Weight:115g
Step 1:Disconnect power supply to AP/Router;
Step 2:Detach the antenna from your certified wireless AP/Router
Step 3:Connect Rg316 cable to the booster and AP/Router
Step 5:Connect the power supply to the booster first and subsequently the AP/Router
Company Information
SZHUASHI Wireless Technology Co., Ltd. is located in Suzhou Industrial Park. Founded in 2010. The only official shop on ! We sell our own products at the best price, such as WiFi amplifier, VCO, sweep signal source, wireless card group and other product lines;Professional people do professional things. We have mastered some core technologies in the product field and have a number of independent intellectual property rights. Our products have been sold to many domestic cities, but also very popular with many foreign customers, such as Russia, the United States, South Korea, Vietnam, Sweden and so on.
