Supermicro SuperServer CSE-827 12x3.5" Bay 2x Node X10DRT-P 4x E5-2680v3 2.50GHzChassis P/N: CSE-827Node P/N: X10DRT-P In Good Condition, Full Working OrderTested2 Year WarrantySupplied With Bezel And Rails Included: - 1 x Supermicro SuperServer
- 2 x Power Supplies 2000W Power Supply PWS-2K02P-1R
- 1 x Backplane - BPN-SAS3-827HD2-N4 rev 1.00
- 12 x 3.5" HDD Caddies
- 2 x Server NodesX10DRT-P nodeseach with
- 2 x Intel Xeon Twelve-Core E5-2680v3. 2.50GHz Processors With 2 x Heatsinks
- 32GB Ram
- Motherboard - Super X10DRT-P rev 1.02
- 2 x full height PCIe slots
- Backplane - BPN-853008N42U
- 16 x DDR4 DIMM Memory Slots
- 1 x 64GB SATADOM-SL 3IE3
Full Manufacturers specification: MBD-X10DRT-P Physical StatsForm Factor Dimensions - 6.8" x 18.86" (17.27cm x 47.9cm)
Processor/CacheCPU - Intel® Xeon® processor E5-2600 v3, Intel® Xeon® processor E5-2600 v4.
- Dual Socket R3 (LGA 2011) supported, CPU TDP support Up to 145W
Cores / Cache - Up to 22 cores † / Up to 55MB† cache
Note - † BIOS version 2.0 or above is required
Note - ** Motherboard supports this maximum TDP. Please verify your system can thermally support.
System MemoryMemory Capacity - 2TB 3DS ECC RDIMM, DDR4-2133MHz; Up to 2TB 3DS ECC LRDIMM, in 16 DIMM slots
Memory Type - 2400/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit
DIMM Sizes - RDIMM: 4GB, 8GB, 16GB, 32GB, 64GB
- LRDIMM: 32GB, 64GB
- 3DS LRDIMM: 128GB
Memory Voltage Error Detection - Corrects single-bit errors
On-Board DevicesChipset SATA - Intel® C612 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
AHCI SATA - SATA3 (6Gbps); RAID 0, 1, 5, 10
SCU SATA - SATA3 (6Gbps); RAID 0, 1, 5, 10
IPMI - Support for Intelligent Platform Management Interface v.2.0
- IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
- ASPEED AST2400 BMC
Network Controllers - Dual LAN with Intel® Ethernet Controller I350-AM2
Single LAN with Virtual Machine Device Queues reduce I/O overhead
Single LAN with Supports 10Base-T, 100BASE-TX, and 1000BASE-T, RJ45 output
Single LAN with 1 Realtek RTL8211E PHY (dedicated IPMI)
Graphics Input / OutputSATA LAN - 2 RJ45 Gigabit Ethernet LAN ports
- 1 RJ45 Dedicated IPMI LAN port
USB - 3 USB 3.0 ports (2 rear + 1 Type A)
Video Output TPM Expansion SlotsPCI-E - 1 PCI-E 3.0 x16,
- 1 PCI-E 3.0 x8,
- 1 PCI-E 3.0 x8 connector for SMC add-on cards,
- 1 PCI-E 3.0 x16 connector for SMC add-on cards,
- (Both CPUs need to be installed for full access to PCI-E slots and onboard controllers. See manual block diagram for details.)
System BIOSBIOS Type - 128Mb SPI Flash EEPROM with AMI BIOS
BIOS Features - Plug and Play (PnP)
- PCI 2.3
- ACPI 1.0 / 2.0 / 3.0 / 4.0
- USB Keyboard support
- SMBIOS 2.7.1
- UEFI 2.3.1
ManagementSoftware - IPMI2.0, NMI, SuperDoctor® 5, Watchdog
System Management Software Power Configurations - ACPI Power Management
- Power-on mode for AC power recovery
PC Health MonitoringVoltage - +12V, +3.3V, +5V, 3.3V standby, 6 Phase-switching voltage regulator, Memory Voltages, VBAT
FAN - 2x 4-pin fan headers (up to 2 fans), 4 fans with tachometer monitoring, Pulse Width Modulated (PWM) fan connectors, Status monitoring for speed control
Temperature - Monitoring for CPU and chassis environment, CPU thermal trip support, Thermal Control for 4 Fan Connectors (2 fans on backplane), Thermal Monitor 2 (TM2) support, PECI
LED - CPU / System Overheat LED, Suspend static indicator LED, UID/Remote UID
Other Features Operating EnvironmentOperating Temperature Range - 10°C - 35°C (50°F - 95°F)
Non-Operating Temperature Range - -40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range - 8% - 90% (non-condensing)
Non-Operating Relative Humidity Range - 5% - 95% (non-condensing)
