Corning 95-050-41-X Unicam SC OM3/OM4 Multimode 50um Pretium Fiber Optic Connector, Box of 25

This listing is for quantity 25 of 95-050-41-X, individually packaged Corning SC MM UniCam® High-Performance Connector, SC 50 um multimode (OM3/OM4 compatible)
Part Number: 95-050-41-XCorning Cable Systems UniCam® High-Performance Connectors offer best-in-class optical performance in a fast, easy field-termination solution. These high-precision connectors guarantee exceptional insert loss – 0.1 dB typical/0.5 dB maximum per connector pair for multimode, 0.2 dB typical/0.5 dB maximum per connector pair for single-mode. Installation of an LC, SC, or ST® Compatible Connector can be accomplished in about 45 seconds with the UniCam High-Performance Tool Kit. The lightweight, handheld installation tool and the high-performance cleaver virtually eliminate human variability from installation, ensuring terminations are right, the first time, every time. This kit was designed with consideration for the network installers, from the cleaver, with its integrated fiber scrap bin and dual-clamp precision hold, to the installation tool, with its immediate go/no-go response signal. Installation is as easy as strip, clean, cleave, cam and crimp, with exceptional optical performance guaranteed.
Features:

• Part Number 95-050-41-X
• Product Description UniCam® High-Performance Connector, SC, 50 um multimode (OM3/OM4 compatible), ceramic ferrule, logo, single pack, black housing, aqua boot
• Product Type Field-Installable Connectors
• Keyed No
• Fiber Category 50 um MM (OM3/OM4 compatible)
• Units per Delivery 1/1
• Broad operating temperature (-40 deg to 75 deg C)
• Utility and flexibility
• Factory-polished end face
• Consistent optical performance
• Fast termination and no consumables
• Low installation cost
• Minimum insertion loss
• Optimum optical and Listings Passed EIA/TIA 568-B.3
• Intermateability Connectors are FOCIS compliant with TIA/EIA 604-10A and IEC61754-20
• Product Type Field-Installable Connectors
• Technology No-Epoxy/No-Polish
• Keyed No
• Corning Logo Yes
• Packaging Single Pack
• Fiber Category 50 um MM (OM3/OM4 compatible)
• Operation -40 deg C to 75 deg C exceeding EIA/TIA 568-B.3 (-40 deg F to 167 deg F exceeding EIA/TIA 568-B.3)
• Connector Type SC
• Ferrule Ceramic
• Housing Material Composite
• Housing Color Black
• Boot Color Aqua
• Durability ? 0.2 dB change by 500 rematings, FOTP-21
• Tensile Strength Jacketed Cable 44 N, change ? 0.2 dB, FOTP-6 (10 lb, change ? 0.2 dB, FOTP-6)
• Tensile Strength 900u Cable 2.2 N, change ? 0.2 dB, FOTP-6 (0.5 lb, change ? 0.2 dB, FOTP-6)
• Temperature Cycling ? 0.3 dB IL, -40 deg to +75 deg C, 21 cycles
• Nominal Fiber Outer Diameter 125 um
• Insertion Loss, Typical 0.1 dB
• Insertion Loss, Max. 0.5 dB
• Reflectance ? -20 dB
• RoHS Free of hazardous substances according to RoHS 2002/95/EG
