COMExpress? Compact Type 2 module, Intel® Atom? processor Z5xx series and Intel®USW15
FormfactorCOM Express CompactCPUIntel® Atom? Z530(1.6 GHz, 512)Intel® Atom? Z510(1.1 GHz, 512)DRAMmax. 1 GByte DDR2 533 MHzEthernetGigabit Ethernet Realtek RTL8111I/O InterfacesPCI bus Rev. 2.3I²C busLPC bus2 x SATA2 x PCI Express?8 x USB 2.01 x EIDE (UDMA-66/100)GraphicsIntel® GMA 500
up to 256 MByte frame buffer supporting Direct X 9.0E and Open GL 2.0Congatec Board ControllerMulti Stage Watchdog, non-volatile User Data Storage, Manufacturing and Board information, Board Statistics, BIOS Setup, Data Backup, I²C bus (fast mode, 400 kHz, multi-master), Power Loss ControlEmbedded BIOS FeaturesOEM LogoOEM CMOS DefaultsLCD ControlBacklight ControlFlash UpdateAMIBIOS8®SecurityThis congatec COM Express Compact board can be optionally equipped with a discrete ?Trusted Platform Module? (TPM).
It is capable of calculating efficient hash and RSA algorithms with key lengths up to 2,048 bits and includes a real random number generator. Security sensitive applications such as gaming and e commerce will benefit also with improved authentication, integrity and confidence levels.Power ManagementACPI 3.0
ACPI 3.0 compliant, Smart Battery ManagementOperating SystemsMicrosoft® Windows® XPMicrosoft® Windows® embedded StandardMicrosoft® Windows® CE 6.0LinuxMicrosoft® Windows® 7Windows Embedded Compact 7TemperatureStandard
Operating: 0 to +60°C Storage: -20 to +80°CHumidityOperating: 10 to 90% r. H. non cond. / Storage 5 to 95% r. H. non cond.Video Interfaces1 x LVDS 1x241 x SDVOSize95 x 95 mm (3,74" x 3,74")
