Notifier XP6-R Six Relay Control Module: Versatile Relay Control for Fire Systems

TheNotifier XP6-R Six Relay Control Moduleprovides reliable and space-efficient relay control within intelligent fire alarm systems. Designed to activate a wide range of auxiliary devices, this module allows system integrators to manage multiple outputs without the need for separate modules or bulky wiring configurations.

Key Features

Six Independently Controlled Relays
Each of the six Form-C relays operates independently, allowing the XP6-R to activate different systems simultaneously or in sequence. For example, it can control elevator recall, door holders, HVAC shutdown, or notification circuits—all from one module.

Compact Design
Despite its six-relay capacity, the XP6-R features a compact footprint. This helps reduce cabinet space requirements, which is especially useful in large or complex installations where real estate is limited.

Flexible Mounting and Wiring
The module mounts on a CHS-6 chassis and supports T-tap wiring, which simplifies installation and improves wiring efficiency. As a result, technicians can complete the setup faster and with fewer complications.

Status LEDs for Each Relay
Each relay includes an individual LED indicator that provides instant response during testing or activation. Consequently, troubleshooting and maintenance are more straightforward.

Intelligent Device Addressing
Using Notifier’s FlashScan protocol, the XP6-R supports individual device addressing and faster communication with the control panel. This ensures precise activation and system-wide synchronization.

Application and Usage

The XP6-R is ideal for:

• High-rise buildings needing elevator recall or smoke control

• Hospitals and campuses with complex notification zones

• Facilities requiring control of multiple power or fan systems

• Environments where relay redundancy is important

Because it centralizes multiple control points in one device, it improves efficiency while reducing wiring complexity.

Installation Tips

To get the best results:

• Mount the module securely to a CHS-6 chassis inside an approved enclosure.

• Label each relay output clearly to avoid confusion during maintenance.

• Connect supervision resistors properly to prevent trouble signals.

• Test each relay function individually after programming to confirm correct operation.

Also, maintaining clean and organized wiring helps with long-term reliability and easier service.

Advantages

• Space Saving: Combines six relays into one module, reducing cabinet needs.

• Flexible Control: Each relay operates independently for custom configurations.

• Fast Communication: FlashScan protocol ensures quick relay response.

• Easy Troubleshooting: Status LEDs help identify activation states.

• Reliable Operation: Built for long-term performance in critical systems
