Product specifications
System
Language Chinese/English
Operating system Linux
Interface Web or mobile app
Processor
CPU ARM Dual-Core [email protected]
Memory DDR 2Gb
Flash 2Gb
Video/Record
Video input
Front 1080P, horizontal 105 °, vertical 62 °; Rear 1080P, horizontal
122 °, vertical 63 °. Video format H.264/H.265
Resolution 1080P, 720P, D1 optional
Quality Available in levels 1-4
Record Mode Record on startup
Audio
Audio input Built-in MIC
Audion output Built-in amplifier, built-in 2W speaker
Audion format G.711A
4G Built in 4G, TDD-LTE, FDD-LTE
WiFi Built-in WiFi for viewing videos and configuring parameters
GPS Gmouse GPS
G Sensor Built-in 3-axis acceleration sensor
SOS Support
I/O output Supports 1 I/O alarm output
Serial port
S22 supports 2 RS232. Can be connected to oil level sensors, RFID
card readers, etc
Upgrade Firmware Support TF card and FTP firmware upgrade
Port
TF Card Maximum support for 512G TF card
USB Support
SIM Card 1 SIM card Port
AI algorithm
(3 options 2)
ADAS FCW, LDW, HMW, PCW
DSM
Smoking, making phone calls, yawning, dozing, distracted, driver not
detected, blocking cameras, sunglasses identification
Face recognition FR
Power
Management
Adaptive broadband power input with protection functions such as
overload, undervoltage, short circuit, and reverse connection. Input voltage DC:+9V ~ +36V
Consumption Normal work ＜ 5W (without -20℃ to +70℃
Humidity 20% to JT/T808-2019, JT/T1076-2016, JT/T1078-2016
UVMS, CMSV6
Size 125mm*85mm*45mm
