1987 Apple IIGS Hardware Reference NO SCHEMATICS ROMs Graphics Memory Map 65816
Price: US $65.00

RARE Apple IIGS Hardware Reference

IncludesComplete Data Sheet for the 65C816~ NO SCHEMATICS ~

Very scarce title. A complete guide to the Apple IIGS internals.


PLEASE NOTE: This specific copy does not include the schematics appendix. Ex-lib. Apart from a little cover wear, the book is in very good condition. Hardcover, 288 pages. Copyright 1987. This item ships WORLDWIDE.



Covers:


- Introduction to the IIgs (expansion slots, ports, internals)- Mega II & FPI Subsystems- Memory (ROMs, memory maps, expansion)- Video (video graphics controller, VGC interrupts, display modes)- Sound (sound synthesis, sound GLU, Ensoniq DOC)- Apple Desktop Bus- I/O Ports & Clock (disk I/O, game port, IWM)- Expansion Slots- Power Supply- 65C816 Microprocessor (complete data sheet, instruction set, 6502 emulation)- Character Generator ROM- 8 Complete Fold-out Schematics
Apart from a little cover wear, the book is in very good condition. Hardcover, 288 pages. Copyright 1987. This item ships WORLDWIDE.
