Key Features & Specifications:

• Connector Type:LC/APC to SC/UPC (Hybrid)

  • LC Connector (Blue body):APC (Angled Physical Contact) polish, 8-degree angled endface. Thegreen ferruledistinguishes it as APC. This design minimizes back reflection, making it ideal for applications sensitive to return loss, such as GPON, CATV, and FTTx.

  • SC Connector (Blue body):UPC (Ultra Physical Contact) polish. Theblue ferruledistinguishes it as UPC. Provides excellent low insertion loss for general connectivity.

• Fiber Type:G657A1 Bend-Insensitive Single-Mode Fiber (SMF).

  • Exceptionally resistant to macro-bend and micro-bend losses, allowing for tighter turns and easier installation in confined spaces like wall ducts, patch panels, and customer premises.

  • Compatible with standard G652D fiber.

• Cable Construction:

  • Jacket Material:LSZH (Low Smoke Zero Halogen). Enhances safety in indoor environments by emitting minimal smoke and no toxic halogen gases in case of fire.

  • Cable Diameter:2.0mm. A slim, flexible, and durable design for easy routing and space-saving cable management.

  • Simplex:Contains one optical fiber.

• Optical Performance:

  • Wavelength:1310nm & 1550nm (Single-Mode).

  • Insertion Loss:Typically ≤ 0.3 dB.

  • Return Loss:

    • LC/APC end: ≥ 65 dB (Excellent for reducing reflected light).

    • SC/UPC end: ≥ 50 dB (Standard high
