DESCRIPTION
TTL To RS485 (C) Galvanic Isolated Converter, Half-Duplex Communication, Lightningproof & Anti-Surge, Multi-Isolation ProtectionTTL To RS485 (C)
Galvanic Isolated Converter

Castellated Holes With Immersion Gold process, Compact size, Easy to integrate

Features At A Glance

• Compatible with TTL/RS485 standard, converting the TTL signal into differential RS485 signal, supports half-duplex communication
• Compatible with 3.3V ~ 5V TTL signal level, provides over-voltage protection for power supply interface
• Onboard unibody power supply isolation, provides stable isolated voltage and needs no extra power supply for the isolated terminal
• Onboard unibody digital isolation, allows signal isolation, high reliability, strong anti-interference, low power consumption
• Onboard TVS (Transient Voltage Suppressor), effectively suppresses surge voltage and transient spike voltage in the circuit, lightningproof & anti-electrostatic
• Onboard self-recovery fuse and protection diodes, ensures the current/voltage stable outputs, provide over-current/over-voltage protection, improve shock proof performance
• Onboard RS485 output terminal 120R resistor, enabled via soldering
• Black immersion gold process design, compact size, easy to TYPEGalvanic isolated TTL To RS485 converterPOWER SUPPLY INTERFACEPower supply3.3V ~ 5VProtectionover-voltageDEVICE PORTTTL/RS485 standard compatibleTTLTransmission distanceLess than 10mTransmission modepoint-to-pointRS485Protection200W lightningproof and surge-suppress, 6KV ESD protectionTerminal resistor120R, enabled via solderingTransmission DistanceAbout 1.2kmTransmission Modepoint-to-multipoint (up to 32 nodes, it is recommended to use repeaters for 16 nodes or more)APPEARANCEDimensions42.8 x 15.2 x 4.75mm
  Primary Function

  Converting The TTL Signal Into Balanced Differential RS485 Signal
  For Interface Converting, Expanding Nodes And Long-Distance Communication

  Multiple Protection, Safe And Stable

  Onboard power and signal isolation, provide stable isolated voltage, high reliability and strong anti-interference. Onboard Lightningproof Diodes and TVS (Transient Voltage Suppressor), effectively suppress surge voltage and transient spike voltage in the circuit, lightningproof & anti-electrostatic. Onboard self-recovery fuse and protection diodes, ensures the current/voltage stable outputs, provides over-current/over-voltage protection, improves shock proof performance


  Compact And Easy Integration

  Castellated Holes With Immersion Gold Design, Highly Integrated Packaging
  Supports Multiple Ways To Be Embedded Into Various Product Applications


  Interface IntroductionINDICATORSR (RXD)RX indicator, lights up when the TTL port receives dataT (TXD)TX indicator, lights up when the TTL port sends dataPWRPower indicator, lights up when there is power supply connection and voltage is detectedLEFT SIDE INTERFACERIGHT SIDE INTERFACEPERS485 signal groundGNDGround / TTL signal groundRXDTTL receive data pinB-RS485 differential signal B-TXDTTL transmit data pinA+RS485 differential signal A+VCCPower Input
  DC 3.3V~5V power supply
  Communication Connection Diagram

  TTL convert to RS485, point-to-point, half-duplex communication, suitable for interface conversion




  TTL convert to RS485, point-to-multipoint, half-duplex communication, suitable for expanding nodes




  Two groups TTL To RS485 conversion, point-to-point, half-duplex communication, suitable for extending the communication distance of TTL



  DimensionsResources & Services
  PACKAGE CONTENT

  Weight:0.003 kg

  TTL TO RS485 (C) x1


  PACKAGE CONTENT

  Weight:0.003 kg

  TTL TO RS485 (C) x1
