5-13GHz angle reflection ultra wideband directional antenna UWB WiFi 6E high gain antenna
Angular reflector ultra wideband directional antenna is a high-performance ultra wideband antenna designed specifically for harsh RF applications. Covering a wide frequency range of 5GHz to 13GHz, it can provide stable and reliable signal transmission, making it very suitable for spectrum monitoring, signal analysis, and communication testing
Waiting for application scenarios.

Product features:
Broadband coverage: Supports ultra wide frequency bands from 5GHz to 13GHz, suitable for various communication testing needs, with low signal loss and stable performance.
High gain design: Achieve a stable gain of 10dBi, ensuring signal reception and transmission strength even in complex environments.
Low return loss: The carefully designed feeding structure reduces the return loss to below -10dB, minimizing signal reflection loss and improving signal quality
Number integrity.
High efficiency and low loss substrate: using high-performance PCB materials, greatly reducing signal loss, ensuring efficient transmission and stability.
High quality SMA interface: equipped with high-quality gold-plated SMA interface, ensuring low insertion loss and providing excellent durability, suitable for long-term use.
Excellent directionality: precise radiation design, clear signal direction, effectively reducing interference, and improving long-distance communication quality.
Applicable scenarios:
Wireless communication testing
Spectrum monitoring and analysis
Electromagnetic Compatibility (EMC) Testing and Diagnosis
laboratory measurement
Field strength monitoring
Technical parameters:
Parameter specifications
Frequency range: 5 GHz -13 GHz
Gain: 10 dBi typ
Return loss:<-10dB
Connector Type: SMA (Gold Plated)
Polarization method: linear polarization
Directionality: High directionality
Material: PTFE
Working temperature: -40 ° C to +85 ° C
