1.3 inch OLED IIC Display Module 128x64 Pixel Mini -Luminous Display Screen Board Applications:
MP3, MP4, ,Head-mounted displays,Meters and other intelligent instruments. Design any pretty patterns for your beloved electronic devices Specifications:
Module interface:IIC,4PIN
Effective display area:29.4x14.7(mm)
Module size:33.7x35.5(mm)
Field of View:>160°
Pin Definition:GND,VCC,SCL,SDA
Voltage:3.3 V ~ 5V DC
Working Temperature:-20~60 degree
High Resolution:128 x 64 Pixels
Driver IC:SH1106 Displya
Display : OLED (Organic Light Emitting Diode
Energy Consumption (Normally): 0.06W
Working Temperature: -20°to 60°
Drive Duty: 1/64 Duty Package include:
5PCS * 1.3 Inch Disyplay Module
10PCS* Female to Female Dupont Wire
10PCS* to Female Dupont Wire
Size: 1.3 inches, Resolution: 128 x 64;Viewing angle:>160°;Supported voltage: 3.3V-5V DC,no need for level conversion chips;Power consumption during normal operation: 0.06W;Full screen illumination: 0.08W;Color:White
Embedded driver IC: SH1106;Communication: I2C/IC interface, only requires I/O ports, with R3 board and Arduino Mega, Raspberry Pi, 51 MCU, STIM 32, MMDVM, Pi Star, etc
No backlight required, each pixel emits light independently. It has ultra-high contrast, high resolution, bright and clear dots, making it easy to read even in small fonts
Graphics and text information can be directly displayed on microcontroller projects, and OLED controllers do not have embedded fonts. Users can create fonts through font generation software
Equipped with 20 DuPont wires (10 -female and 10 female) to increase convenience
