The performance of fiber optic connectors is first of all optical performance, in addition to the interchangeability, repeatability, tensile strength, temperature and number of insertions and removals of fiber optic connectors.Optical performance: The optical performance requirements of fiber optic connectors are mainly the two basic parameters of insertion loss and return loss.Insertion Loss is the loss of the effective optical power of the link caused by the introduction of the connector. The smaller the insertion loss, the better. Generally, the requirement should be no more than 0.5dB. 2, interchangeability, repeatabilityThe fiber optic connector is a universal passive device. For the same type of fiber optic connector, it can be used in any combination and can be used repeatedly. Therefore, the additional loss introduced is generally less than 0.2 dB.3, tensile strengthFor a good fiber optic connector, the tensile strength is generally required to be no less than 90N.4, temperatureGenerally, fiber optic connectors must be able to operate at temperatures between -40oC and +70oC.5, the number of plugs Currently used fiber optic connectors can be plugged and unplugged more than 1000 times.Specifications
Fiber Type
SM
Surface polishing
SC/APC/UPC
Color
Green
insertion loss
0.2dB
return loss
≥60dB
joint endurance
10Times
Material of shell
ABS
Applications
2.0/3.0 or FTTH patch cord
Fiber Diameter
125um
Tensile Strength
>20N
Lock Strength
0.2dB
Temperature Cycle
0.3dB
Virbration
0.2dB
Temperature
