AHD features:

Long distance of a network laying without quality losses Video data is transmitted without quality losses at the distance of 500 m. Qualitative video without latencies No signal latencies, indicative for IP-systems.

If you buy 5MP, please make sure your DVR supports AHD 5MP camera.

Model

AHD 2.0MP (1080P)/5MP

Sensor

1/2.9 inch CMOS sensor

Minimum Illumination

Color:0. 01Lux,(F1.2,AGC ON),0Lux with IR

Black & White:0.001Lux,(F1.2,AGC ON),0Lux with IR

Photosensitive Resistance

1 photosensitive resistance interface, support the photosensitive resistor input signal and image, IR-CUT, infrared lamp linkage

Shutter

1/50(1/60) seconds to 1/10,000 seconds

Day and Night Function

Support IR-CUT

Infrared light

3pcs array IR leds

Lens

1.7mm panoramic lens

Synchronous Mode

inter-sync

Noise-signal Ratio

>58dB

Temperature and Humidity

- 10'C ~ 60'C, humidity is less than 90% (no condensation)

Power

DC12V±10%

Consumption

<5W

Dimension

11.5*8cm

Housing material

Metal

Does not include power supply12V 1A,12V 2A

Note:

MUST use with AHD 1080N/1080PDVR!!

It is not compatible with conventional analog DVR!!!

For reference only
