Product Parameters:
Module Size
38mmx38mmx28.3mm
Sensor
1/1.8-Inch IMX678
Resolution
3840H x 2160V
Pixel Size
2.0*2.0µm
Output Format
MJPEG, YUV2,
FOV
DFOV:92° HFOV:85° VFOV：54°
Lens
M12 P0.5 3G+3P IR 650NM
TV distortion
<1.1%
FEL
4.2
F/NO
2.0
Focus Type
FF
Shutter Type
Electronic Rolling Shutter
Output and Power Supply
High Speed USB3.0
Interface
TYPEC - USB3.0
Controllable Parameters
Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White Balance, Backlight Contrast, Exposure
Supported OS
Windows10,Windows11, Android, Linux,
Resolutionsand Frame Rates：
Format
Resolution
Frame Rate (USB3.0)
MJPG
3840x2160(4K)
60FPS
2560x1440(2K)
60FPS
2592x1944(5MP)
60FPS
2048x1536(3MP)
60FPS
1600x1200(2MP)
60FPS
1920x1080 (1080P)
60FPS
1280x720 (720P)
60FPS
640x480 (VGA)
60FPS
YUY2
3840x2160(4K)
15FPS
2560x1440(2K)
30FPS
2592x1944(5MP)
30FPS
2048x1536(3MP)
30FPS
1600x1200(2MP)
30FPS
1920x1080 (1080P)
30FPS
1280x720 (720P)
30FPS
640x480 (VGA)
30FPS
Package Include:1x USB Camera Module
